18 EB 8355-1 EN
Mounting on control valves
Table1: Lever (see Fig.3)
Mounting kit
Actuator size Lever with associated clamp and intermediate plate Order no.
120cm² D1 lever with stopper for output (38)
Standard version 1400-7116
Version compatible with paint 1402-0944
240/350cm² D1lever(33mmlongwith17mmclamp)
Standard version 1400-6370
Version compatible with paint 1402-0942
355/700cm² D2lever(44mmlongwith13mmclamp)
Standard version 1400-6371
Version compatible with paint 1402-0943
Table2: Switchover plates and connecting plates
Order no.
Switchoverplate(for120cm²actuator) Type3277-5xxxxxx.00 Actuator (old) 1400-6819
New switchover plate Type3277-5xxxxxx.01 Actuator (new) or higher 1400-6822
Connecting plate for additional attachment
of, e.g. a solenoid valve
Type3277-5xxxxxx.00Actuator(old),G
1
/
8
Type3277-5xxxxxx.00 Actuator (old),
1
/
8
NPT
1400-6820
1400-6821
New connecting plate
Type3277-5xxxxxx.01 Actuator (new) or higher
G
1
/
8
and
1
/
8
NPT
1400-6823
Note: Only new switchover and connecting plates can be used with new actuators (Index 01). Old and new plates
are not interchangeable.
Requiredconnectionblockfor240,350,355and700cm²
actuator (including gaskets and fastening screw)
G¼ 1400-8819
¼ NPT 1402-0901
Table3: Pipe connection
Material Actuatorsize[cm²] Order no.
Requiredpipeconnectionincludingscrewtting
For actuator with "actuator stem retracts" or
with air purging of the top diaphragm chamber
Steel 240 1400-6444
Stainless steel 240 1400-6445
Steel 350 1400-6446
Stainless steel 350 1400-6447
Steel 355/700 1400-6448
Stainless steel 355/700 1400-6449
Table4: Range spring
Travel[mm] Actuatorsize[cm²] Order no.
2(4.5coils) 7.5 120, 240 1400-6443
1(9.5coils,installedasstandard) 10to15 120,240and350 1400-6442
2 15 355/700 1400-6443
1 30 355/700 1400-6442
