Samson 4763 - Article Code

2-2 EB 8359-2 EN
Markings on the device
2.2 Article code
Electropneumatic Positioner Type4763- x 1 x 0 0 x x x x 0 x 0 x x 0
Explosion protection
Without 0 2/7
ATEX:
II 2G Ex ia IIC T6 Gb
1
CCC Ex: Ex ia IIC T4 ~ T6 Gb
EAC:
1Ex ia IIC T6/T5/T4 Gb X
CSA: Ex ia IIC T6; Class I, Zone 0
Class I, II, Div. 1, Groups A, B, C, D, E, F, G
Class I, II, Div. 2, Groups A, B, C, D, E, F, G
3
FM: Class I, Zone 0 AExia IIC
Class I, II, III, Div. 1, Groups A, B, C, D, E, F, G
Class I, Div. 2, Groups A, B, C, D;
Class II, Div. 2 Groups F, G; Class III
ATEX: II 3G Ex nA ic IIC T6 Gc 8 2/7
Spring
Spring 1, travel = 15 mm 1
Spring 2, travel = 30 mm, split range 15 mm 2
Spring 3, travel = 60 mm, split range 30 mm 3
Pneumatic connections
ISO228/1G¼ 1
¼-18NPT 3
Electrical connection (cable gland)
M20x1.5 blue (plastic) 1
M20x1.5 black (plastic) 2
M20x1.5 (nickel-plated brass) 7 2
i/p converters
Type6109 1
Type6112 2
Set point
4 to 20 mA 0
0 to 20 mA 2 2
1 to 5 mA 2 3
