Markings on the device
Type4763 up to device index .04 x 0 x x x x x x x x 0
Pneumatic connections
ISO228/1G¼ 1
¼-18NPT 3
ISO-7/1-Rc¼ 4
Electrical connection (cable gland)
ISO228/1G½
0
M20x1.5 blue (plastic)
1
M20x1.5 black (plastic) 2
Harting connector HAN 7D 5
M20x1.5 blue (metal) 6
M20x1.5 (metal) 7
i/p converter
Type6109 1
Type6112 2
Set point
4 to 20mA 1 1
4 to 20mA 2 1
0 to 20mA 2 2
1 to 5 mA 2 3
