Samson C COM16 - Specifications

20
System Specifications
Frequency Response 20Hz to 20kHz + - 0.5 dB
Dynamic range 95 dBu, un-weighted, 22 Hz to 22 kHz
THD 0.008 % typ. @ +4 dBu, 1 kHz
Crosstalk 90dB 22 Hz to 22 kHz
Detector RMS
Compressor Section
Sensitivity -10 dB to +20 dB
Ratio variable (1:1 to 1 : )
Manual Attack Time variable (0.3 ms / 20 dB to 300 ms / 20 dB)
Manual ReleaseTime variable (0.05 to 5 Sec)
Output gain variable (-20 to +20 dB)
Function Switches
ENHANCER In/Out
I/O METER Switches the Input/Output meter to read input or output level.
BYPASS Switches the compression effect circuit in and out.
Operating Level (Rear Panel) Changes the internal reference level from-4 dBu to -10 dBV.
Meters & LED's
Gain Reduction 6 segment LED display:
1/3/6/12/24/30 dB
Input/Output level 6 segment LED display:
OL/+6/0/-6/-18/-30 dB
Function switches LED indicator in each
Audio Input
Connectors 1/4" TRS jack
Impedance 20k Ohm balanced, 10k Ohm unbalanced
Nominal Operating Level Selectable +4dBu/-10 dBV
Max. Input Level +21 dBu, balanced and unbalanced
CMRR Typ. 40dB, >55dB @ 1kHz
Audio Output
Connectors 1/4" TRS jack
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Max. Output Level +21 dBu, balanced and unbalanced
Key Insert
Connector 1/4" TRS jack
Impedance >10 k Ohm
Max. Input Level +21 dBu
Power Supply
AC1800 USA/Canada
AC1800UK U.K.
AC1800E Europe
AC1800AU Australia
Size
Dimensions 1.61" (41 mm)H x 8.67” (220.68 mm) x 7.5 (192 mm)
Weight
Net Weight 2.68 lbs (1.22 kg)
Shipping Weight 7.5 lbs (3.4 kgs)
Specifications
∞
