5-5
5. Exploded View & Part List
5-3. LN40B550K1H Parts List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
LN40B550K1HXZA LN40B550K1H,N64D/40BK1-G5K,40,LCD-TV,UNI
0.1 M0001 BN90-01959N ASSY COVER FRONT;LB550 40 1 S.N.A
..2 T0175 BN96-09463C ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:60 1 S.A
..2 T0003 BN96-09668N ASSY COVER P-FRONT;LB550 40,UO(HOTEL),PC 1 S.A
...3 T0069 BN60-00027G SPACER-FELT;L650-40,FELT,890,0.5,20 2 S.N.A
...3 T0069 BN60-00027P SPACER-FELT;L650 40,FELT,502,0.5,20 2 S.N.A
...3 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 7 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 2.8 S.N.A
...3 M0112 BN63-05457A COVER-FRONT;40,LB550,UO,PC(CLR)+PC(ROSE 1 S.N.A
...3 BN96-09678A ASSY HOLDER P-BOSS BOT;LB550 40,HIPS,V0, 1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.06 S.N.A
....4 BN61-05111A HOLDER-BOSS BOTTOM;40,LB550,HIPS,V0,BK50 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.8 S.N.A
....4 BN61-04731C BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.675 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.12 S.N.A
...3 BN96-09683A ASSY HOLDER P-SIDE,R;LB550 40,PC+ABS,V0, 1 S.N.A
....4 BN61-05115A HOLDER-BOSS SIDE;40,LB550,PC+ABS,V0,BK50 1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.03 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.05 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.28 S.N.A
...3 BN96-09683B ASSY HOLDER P-SIDE L;LB550 40,PC+ABS,V0, 1 S.N.A
....4 BN61-05115B HOLDER-BOSS SIDE;40,LB550,PC+ABS,BK500,V 1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.03 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.05 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.28 S.N.A
...3 M0175 BN96-11209B ASSY BOARD P-TOUCH FUNCTION&IR;EU/US/ASI 1 S.A
...3 H/B/SIDE+C 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 CCM1 BN63-05199F COVER-SHEET;AMBER,PE,T0.08,W95mm,200M,CL 1.2 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 0.7 S.N.A
0.1 M0002 BN90-01975E ASSY COVER REAR;LB550 40 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 9 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 M0013 BN96-09713D ASSY COVER P-REAR;LB550 40,UO(HOTEL),HIP 1 S.N.A
...3 T0101 BN61-04816A BRACKET-WALL;40, B610,SECC,T1.2 4 S.N.A
...3 BN63-01925A FELT-VIBRATION;42D5,FELT,T0.35,10,370 2 S.N.A
...3 M0006 BN63-05462D COVER-REAR;LB550 40,UO(HOTEL),HIPS,V0,BK 1 S.A
...3 T0071 BN64-01025C INLAY-TERMINAL;LB550,UO(HOTEL),PS SHEET, 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,BLK 1 S.N.A
0.1 M0216 BN90-02002A ASSY STAND;LB550 37 , 40 1 S.N.A
..2 M0027 BN96-09649A ASSY STAND P-BASE;LB550 37,40,TEMPERED G 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
...3 BN61-04374A BRACKET-STAND BASE;40,46,52L850,SECC,T2. 1 S.N.A
...3 BN61-04428B BOSS-TAPE;ACRYL,T0.4,W20.0mm,WHITE 0.32 S.N.A
...3 BN61-04438A BRACKET-HINGE SWIVEL;40,46,52L850,SECC,T 1 S.N.A
...3 BN61-04439A HOLDER-SWIVEL RING;40,46,52L850,ACETAL 1 S.N.A
