5-15
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 R416 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R619 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R620 2011-000002 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.A
....4 R327 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 1 S.N.A
....4 R330 2011-000515 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,8P,TP, 1 S.N.A
....4 R453 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R488 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R815 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R816 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R907 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R914 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R915 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 R989 2011-000651 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,32 1 S.N.A
....4 FR438 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 FR439 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 FR440 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R445 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R446 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R447 2011-001001 R-NETWORK;0ohm,5%,1/16W,L,CHIP,8P,TP,3.2 1 S.A
....4 R398 2011-001011 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,8P,TP,3 1 S.A
....4 C129 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C141 2203-000041 C-CER,CHIP;0.01nF,0.25pF,50V,C0G,1608 1 S.N.A
....4 C1 2203-000204 C-CER,CHIP;100nF,10%,25V,X7R,2012 1 S.N.A
....4 C2 2203-000204 C-CER,CHIP;100nF,10%,25V,X7R,2012 1 S.N.A
....4 C3 2203-000204 C-CER,CHIP;100nF,10%,25V,X7R,2012 1 S.N.A
....4 C815 2203-000204 C-CER,CHIP;100nF,10%,25V,X7R,2012 1 S.N.A
....4 C1013 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C199 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C905 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C910 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C911 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,1005 1 S.A
....4 C505 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C605 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C715 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C717 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C719 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 S.A
....4 C1012 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C124 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C195 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C201 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C220 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C405 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C449 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C507 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 S.A
....4 C1042 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C1043 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C176 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C177 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C179 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C180 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
....4 C119 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 1 S.A
