5-23
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..2 BR/LINK+H/ 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 BR/TOP+C/F 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 GROUND 6003-001439 SCREW-TAPTYPE;BH,+,S,M4,L8,ZPC(WHT),SWRC 1 S.N.A
..2 M2893 BN39-00618M LEAD CONNECTOR;Hotel Power cable,UL1617# 1 S.A
..2 M2893 BN39-01099V LEAD CONNECTOR;Hotel Power Cable,UL1007# 1 S.A
..2 M2893 BN39-01130L LEAD CONNECTOR;Hotel LB4C,UL1007#26,10,5 1 S.A
..2 T0764 BN44-00257A SMPS-SUB POWER;HT_9,AC/DC,AC90 ~ 264V,50 1 S.A
..2 M0174 BN44-00264A IP BOARD;PSIV231I01A,H40F1_9SS,0.11mA,11 1 S.A
..2 M0146 BN61-04818A BRACKET-PANEL TOP;B650-32,SECC,T1.2 2 S.N.A
..2 M0146 BN61-04819A BRACKET-PANEL TOP;B650-46,SECC,T1.2 2 S.N.A
..2 M0230 BN96-10076A ASSY CABLE P-FPCB LVDS;LA46A650A1,FPCB L 1 S.A
..2 BN61-05284A BRACKET-PCB SMPS;HOLTEL,SECC,T0.8 1 S.N.A
..2 M0254 BN61-04801K HOLDER-SIDE AV;LB530/540,UO,HIPS,V0,BK50 1 S.N.A
..2 M0115 BN61-04918A BRACKET-STAND LINK;40, B610,SECC,T1.6 1 S.N.A
..2 PCB + BR/P 6003-000275 SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),SWR 2 S.N.A
0.1 M0003 BN92-04287P ASSY BOX;LB550 40 1 S.N.A
..2 BN69-03564E BOX-SET,OUT;40LB550,CB,C-03,DW2,YEL,W123 1 S.N.A
..2 BN69-03475B BOX-SET;IN;40LB450,CB,C-01,DW2,YEL,W1525 1 S.N.A
0.1 M0019 BN92-04995A ASSY LABEL;LA40B550K1HXXT 1 S.N.A
0.1 M0045 BN92-05032D ASSY ACCESSORY;LN40B550K1HXZA 1 S.N.A
..2 BN68-01402E MANUAL FLYER-STAND GUIDE;32”,SAMSUNG,Eng 1 S.N.A
..2 M0045 BN96-09870A ASSY ACCESSORY;LN40B550K1HXZA 1 S.A
...3 T0268 3903-000144 CBF-POWER CORD;DT,US,BP3/Y,U(IEC C13-RA) 1 S.A
...3 T0524 6902-000018 BAG PE;LDPE,T0.1,W280,L400,CLEAR,8,2,20. 1 S.N.A
...3 AA68-03242L MANUAL FLYER-04,SAFETY GUIDE;comm,Samsun 1 S.N.A
...3 M0521 BN39-00865B CBF IF-MODULAR/MODULAR;US HOTEL CORAL,6P 1 S.A
...3 M0521 BN39-01011C CBF IF-MODULAR/MODULAR;US HOTEL CORAL/AM 1 S.A
...3 T0074 BN59-00899A REMOCON;L530H,TM950,SAMSUNG,20 Pin,48,AM 1 S.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0531 BN63-05468A COVER-BOTTOM;40,LB550,HIPS,V0,BK500 1 S.A
...3 BN68-01600A MANUAL FLYER-03,LEAFLET;COMM,SAMSUNG,Eng 1 S.N.A
...3 M0560 BN96-01800A ASSY ACCESSORY-SCREW ZIPPER;ROME32,SCREW 1 S.N.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
....4 ACCESSORY 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M 1 S.N.A
...3 BN96-10788A ASSY ACCESSORY-PREVENT;32,LB650,nylon66 1 S.N.A
...3 T0059 BN68-02178A MANUAL FLYER-CARD;COMM,SAMSUNG,eng/spa/c 1 S.N.A
...3 BN68-02226C MANUAL FLYER-QSG;B550,SAMSUNG,ENG/SPA,US 1 S.N.A
...3 BN68-02186A MANUAL FLYER-TOC GUIDE;COMM,SAMSUNG,10 L 1 S.N.A
0.1 M0113 BN92-04300H ASSY P/MATERIAL;LB550 40 (UO) 1 S.N.A
..2 T0524 6902-001043 BAG PE;HDPE/NITRON,T0.015/T0.5,W1200,L80 1 S.N.A
..2 T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g 4 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.39 S.N.A
....4 C3014 2203-006126 C-CER,CHIP;47NF,10%,16V,X7R,TP,1005 1 S.N.A
