5-25
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...3 T0920 BN61-05120A GUIDE-STAND;46,LB550,PC+GF(20%) V0,BLK 1 S.N.A
...3 BN63-05232A COVER-STAND,SUB;46,LB550,ABS+PMMA,HB,BK2 1 S.N.A
...3 BN63-05636A COVER-STAND GLASS;52 B550,GLASS,T8.0,BLK 1 S.N.A
...3 M0126 BN73-00215A RUBBER-FOOT;40LB650,RUBBER,15*25,60,4.0, 2 S.N.A
...3 CCM1 BN63-04755D COVER-SHEET;PE,T0.05,W520mm,200M,600FE,C 0.83 S.N.A
...3 T0132 BN73-00181A RUBBER FOOT;RUBY,CR Rubber,PI 25,T3.5,BL 4 S.N.A
0.1 BN91-04057A ASSY LCD-AMLCD;BN07-00678B,SPVA 72% 1 S.N.A
..2 M0215 BN07-00678B LCD-PANEL;LTF520HB07 1 S.A
...3 BN81-02342A A/S-T CON LTF520HB05;LTF520HB05 1 S.N.A
...3 BN81-02343A A/S-BB-L LTF520HB05;LTF520HB05 1 S.N.A
0.1 M0017 BN91-04201E ASSY CHASSIS;LN52B550K1HXZA 1 S.N.A
..2 M0014 BN94-02945E ASSY PCB MAIN;LN52B550K1HXZA 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 CN802 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN903 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN101 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 CN8_5 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 1 S.N.A
...3 JA333 3722-002691 JACK-PIN;2P,Ni,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002691 JACK-PIN;2P,Ni,WHT/RED,STRAIGHT 1 S.A
...3 CN807 3722-002694 JACK-MODULAR;8P/6C,N,STRAIGHT,N,AU,1PORT 1 S.A
...3 JA333 3722-002703 JACK-PIN;3P,Ni,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002704 JACK-PIN;3P,Sn,YEL/WHT/RED,ANGLE 1 S.A
...3 JA333 3722-002848 JACK-PIN;1P RCA,Ni,BLACK,STRAIGHT 1 S.A
...3 CIS3 BN40-00138A TUNER;TDAU4-K01A,TDAU4-K01A,VSB(NTSC/ATS 1 S.A
...3 X105 BN61-04928A BRACKET-SUPPORT PCB;SPCC,T 0.8,SCREW-M4 1 S.N.A
...3 HDCP BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 VCN105 3711-004183 HEADER-BOARD TO BOARD;BOX,10P,1R,2MM,ANG 1 S.N.A
...3 VCN103 3722-002722 JACK-DC POWER;3P,SN,BLACK 1 S.A
...3 T0066 BP62-00017A HEAT SINK-ES;SP-50L2HX,A6063S,T2.0,26.2, 1 S.N.A
...3 T0174 BN97-03504C ASSY SMD;LN40B550K1H 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,D20~45um,96.5Sn/3A 0.104 S.N.A
....4 D721 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D728 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D729 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D730 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D731 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D810 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D815 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D912 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
