5-42
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..2 BR/LINK+PA 6003-000337 SCREW-TAPTYPE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.N.A
..2 BR/LINK+H/ 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 BR/TOP+C/F 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 GROUND 6003-001439 SCREW-TAPTYPE;BH,+,S,M4,L8,ZPC(WHT),SWRC 1 S.N.A
..2 M2893 BN39-00618L LEAD CONNECTOR;Hotel Power cable,UL1617# 1 S.A
..2 M2893 BN39-01099U LEAD CONNECTOR;Hotel Power Cable,UL1007# 1 S.A
..2 T0764 BN44-00257A SMPS-SUB POWER;HT_9,AC/DC,AC90 ~ 264V,50 1 S.A
..2 M0174 BN44-00267A IP BOARD;PSIV321609A,I52F1_9SS,0.1mA,11m 1 S.A
..2 T0101 BN61-04817A BRACKET-WALL;46, B610,SECC,T1.6 4 S.N.A
..2 M0146 BN61-04819A BRACKET-PANEL TOP;B650-46,SECC,T1.2 4 S.N.A
..2 M0230 BN96-10074A ASSY CABLE P-FPCB LVDS;LA46A650A1,FPCB L 1 S.A
..2 M2893 BN39-00830B LEAD CONNECTOR;LNT4642HX/XAA,UL1061#28,7 1 S.A
..2 M2893 BN39-01021A LEAD CONNECTOR;LN46A550P,UL3239#24,2pin, 1 S.A
..2 M2893 BN39-01021D LEAD CONNECTOR;LB6T,UL3239#24,2P,1200mm, 1 S.A
..2 M2893 BN39-01130L LEAD CONNECTOR;Hotel LB4C,UL1007#26,10,5 1 S.A
..2 M0254 BN61-04801K HOLDER-SIDE AV;LB530/540,UO,HIPS,V0,BK50 1 S.N.A
..2 BN96-11047B ASSY BRACKET P-STAND;LINK;46, B610,T2.0, 1 S.N.A
...3 M0115 BN61-04788A BRACKET-STAND LINK;46, B610,SECC,T2.0 1 S.N.A
...3 BN61-05281A HOLDER-CLAMP;LCD,NYLON 66,WHT 3 S.N.A
..2 PCB + BR/P 6003-000275 SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),SWR 2 S.N.A
..2 BN61-05284A BRACKET-PCB SMPS;HOLTEL,SECC,T0.8 1 S.N.A
0.1 M0003 BN92-04289P ASSY BOX;LB550 52 1 S.N.A
..2 M0521 BN69-03481A BOX-SET,IN;52LB610,CB,C-01,DW1(DY-01),YE 1 S.N.A
..2 BN69-03580E BOX-SET,OUT;52LB550,CB,DW3,YEL,W1547,D27 1 S.N.A
0.1 M0113 BN92-04302A ASSY P/MATERIAL;LB550 52 (UO) 1 S.N.A
..2 T0524 6902-000960 BAG PE;NITRON,T0.015/T0.5,W1600,L1100,TR 1 S.N.A
..2 T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g 4 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.7 S.N.A
..2 T0527 6902-000621 BAG SHEET;HDPE/NITRON,T0.015/T1,W1000,L2 1 S.N.A
0.1 M0019 BN92-04995A ASSY LABEL;LA40B550K1HXXT 1 S.N.A
0.1 M0045 BN92-05032E ASSY ACCESSORY;LN52B550K1HXZA 1 S.N.A
..2 BN68-01402E MANUAL FLYER-STAND GUIDE;32”,SAMSUNG,Eng 1 S.N.A
..2 M0045 BN96-09871A ASSY ACCESSORY;LN52B550K1HXZA 1 S.A
...3 T0268 3903-000144 CBF-POWER CORD;DT,US,BP3/Y,U(IEC C13-RA) 1 S.A
...3 T0524 6902-000018 BAG PE;LDPE,T0.1,W280,L400,CLEAR,8,2,20. 1 S.N.A
...3 AA68-03242L MANUAL FLYER-04,SAFETY GUIDE;comm,Samsun 1 S.N.A
...3 M0521 BN39-00865B CBF IF-MODULAR/MODULAR;US HOTEL CORAL,6P 1 S.A
...3 M0521 BN39-01011C CBF IF-MODULAR/MODULAR;US HOTEL CORAL/AM 1 S.A
...3 T0074 BN59-00899A REMOCON;L530H,TM950,SAMSUNG,20 Pin,48,AM 1 S.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0531 BN63-05469A COVER-BOTTOM;46,LB550,HIPS,V0,BK500 1 S.A
...3 BN68-01600A MANUAL FLYER-03,LEAFLET;COMM,SAMSUNG,Eng 1 S.N.A
...3 M0560 BN96-01800A ASSY ACCESSORY-SCREW ZIPPER;ROME32,SCREW 1 S.N.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
....4 ACCESSORY 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,4-PE M 1 S.N.A
...3 BN96-10788A ASSY ACCESSORY-PREVENT;32,LB650,nylon66 1 S.N.A
...3 T0059 BN68-02178A MANUAL FLYER-CARD;COMM,SAMSUNG,eng/spa/c 1 S.N.A
