3-3
3. Disassembly and Reassembly
Description Picture Description Screws
6. Remove the 2 screws of the sub SMPS.
7. Remove the left and right speaker.
8. Remove the 6 screws of bottom bracket
stand link.
9. Remove 2 screws.
