2-2) Specifications
Defrost Control From 12 to 30hrs(comp. run time)
Thermo Bimetal Protector 140°F(60°C)(off) 104°F(40°C)(on)
Defrost Thermistor(502AT) 50°F(10°C)(off)
Electrical Rating AC115V 60Hz 11.6 Amps
Maximum Current Leakage 0.25 mA
Maximum Ground Path Resistance 0.1 Ohm
Energy Consumption 481 kWh/year
Refrigerator,°F 44°F(7°C) ~ 34°F(1°C)
Freezer,°F 5°F(-15°C) ~ -8°F(-23°C)
Run Time,% < 40 < 80
Refrigerant Charge (R134a) 5.64 oz(160g)
Compressor(MKV190C-L2J) 1314 Btu/hr(0.385kw)
Compressor oil Freol 5
∝
15c
R Capillary tube(Dia, Length) 0.032",118"(0.82mm,3500mm)
Clearance must be provided for air circulation.
AT TOP 1"(25mm)
AT SIDES 1"(25mm)
AT REAR 2"(50mm)
