41
3-20) Ice-Maker
Ice Maker
1. When pressing the Energy-Saver and the
Fridge buttons on the Display together for
8 seconds at the same time, it will convert
to the Test Mode and the entire Display
function will be off.
2. When pressing any button within 15 seconds
after it is shifted to the Test Mode, its
function will change in the following order.
Manual operation1(FF) Manual
operation2(0F-r) -> manual defrost of fresh
food compartments(rd) -> manual defrost
of fresh and freezer compartments(fd) ->
cancel(Display all off).
● Set unit to Fd for 5 minutes. This will allow
for easy removal of the ice maker.
3. While pressing the tab on the top right side,
lift up the Ice Bucket and pull it out
Button
4. Remove the screw from the Wire Housing
Cover.
5. Remove the Wire Housing Cover.
6. Disconnect the Ice Maker Housing
Connector.
To Next Page
