Samsung RF263BEAE** - 3-26) Machine Compartment

46

3-26) Machine Compartment
  
Motor Fan
1. Unscrew 5 screws of cover compressor.
2. Disengage the housing connector.
(Refer to the picture)
CAUTION
Before doing the above, make
sure that the unit is unplugged.
3. Remove the bracket of support circuit motor
by lifting the bracket up and pulling it out.
4. Remove the screw with a flat-blade
screwdriver.
(Refer to the picture)
5. Remove the motor fan by pulling the fan out
while holding the motor part.
(Refer to the picture)
6. Unscrew 2 screws fixed in the motor.
7. Remove the hook of the motor cover with a
flat-blade (-) screwdriver and then remove
the motor.
