31
3-7) Water-Dispenser
Water-Dispenser
1. Disengage the Housing Connector by
pushing a flat-blade screwdriver.
2. Remove 2 screws of the Case Ice Route
Assy.
3. Pull the Case Ice Route Assy.
4. Assembly shall be in order from the
disassembly. Case-Ice and Route shall
be assembled inside of hose. Otherwise,
assemble cannot be accomplished.
5. When assembling Cover-Display, first
insert it from leftside and then assemble to
rightside.
Otherwise, the hook can be broken.
To Next Page
