Samsung SCX-6555N Service Manual

Reference Information
Service Manual
7-4
Samsung Electronics
7.3 Acronyms and Abbreviations
The table below explains abbreviations used in this service manual.
The contents of this service manual are declared with abbreviations in many parts. Please refer to the
table.
7.3.1 Acronyms
ABS Automatic Background Suppression(a
kind of copy feature)
APF Automatic Paper Feeder(Tray)
BOOTP BOOTSTRAP PROTOCOL
CCD Charged Coupled Device
CIS Contact Image Sensor
CPM Copies Per Minute
CP Control Panel(= OPE)
CQ Copy Quality
CRU Customer Replaceable Unit
CRUM CRU Memory
CW Center Ware
CWDP Center Ware Device Discovery
Software(Samsung equivalent of
Samsung’s SyncThru)
CWIS Center Ware Internet Services
DADF Duplex Auto Document Feeder
(= DADH)
DC Direct Connect
DDNS Dynamic Domain Name System
'+&3 '\QDPLF+RVW&RQ¿JXUDWLRQ3URWRFRO
DLC Data Link Control
DNS Domain Name System
ECM Error Correction Mode
ECP Enhanced Capability Port
e-Coil Extended Coil technology for
Rapid(Fast) Fusing.
EH&S Samsung Environment, Health,
& Safty
ESMTP Extended Simple Mail Transfer Protocol
EP Electro Photography
EPC Electric Pre-Collation
FCOT First Copy Out Time
FDI Foreign Device Interface
FIA Foreign Interface Attachment
FRU Field Replaceable Unit
FPOT First Print Out Time
GW GateWay
HH High Temperature, High Humidity
(Testing Chamber conditions)
HPVC Halftone Printing Video Controller in the
SPGPm (Graphic Processor for Copy)
IDC International Data Corp.
IMAP Internet Message Access Protocol
IPP Internet Printing Protocols
IPM Images Per Minutes
IPX Internetwork Packet Exchange
IQ Image Quality
ITU International Telecommunication Union
JBIG Joint Binary Image Group
(a kind of image data coding method)
JPEG Joint Photographic Expert Group
(a kind of image data coding method)
LCD Liquid Crystal Display
LEF Long Edge Feeding
LL Low Temperature, Low Humidity
(Testing Chamber conditions)
LPR/LPD Line Printer Daemon Protocols
(LPR is a TCP-based protocol)
LSU Laser Scanning Unit
LUI Local User Interface
MCBF Mean Copy Between Failure
MDSP Multiple Document Single Printout
MFP Multi-Functional Product
0+ 0RGL¿HG+XIIPDQ
(a kind of image data coding method)
CÓPIA NÃO CONTROLADA
CÓPIA NÃO CONTROLADA

Samsung SCX-6555N Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	8 s
Duplex print speed (ISO/IEC 24734) mono	48 ipm
Print speed (black, normal quality, A4/US Letter)	55 ppm
All-in-one functions	Copy, Print, Scan
Color all-in-one functions	Scan
Digital sender	No
Maximum duty cycle	250000 pages per month
Optional functions	Fax
Page description languages	PCL 5e, PCL 6, PDF 1.4, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2
Time to first copy (black, normal)	5 s
Copy speed (black, normal, US Letter)	55 cpm
Scan to	E-mail, FTP
Scanner type	Flatbed & ADF scanner
Maximum scan area	Legal (216 x 356) mm
Image formats supported	TIF
Maximum scan resolution	4800 x 4800 DPI
Document formats supported	PDF
Paper input type	Paper tray, Sheetfed
Total input capacity	720 sheets
Total output capacity	500 sheets
Maximum input capacity	3240 sheets
Total number of input trays	3
Auto document feeder (ADF) input capacity	100 sheets
Envelopes sizes	10, B5, C5, C6, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper, Transparencies
Paper tray media weight	0 - 75 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Letterhead
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	0 - 80 g/m²
Auto Document Feeder (ADF) media weight (imperial)	0 - 20 lbs
Display	LCD
Product color	White
Display resolution	640 x 240 pixels
Market positioning	Business
Direct printing	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Authentication method	LDAP
Mobile printing technologies	Not supported
Internal memory	256 MB
Maximum internal memory	512 MB
Internal storage capacity	80 GB
Sound power level (standby)	43 dB
Sound pressure level (copying)	62 dB
Sound pressure level (printing)	60 dB
Power consumption (average operating)	- W
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64
Windows operating systems supported	Windows 2000, Windows 98, Windows ME, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	489 mm
Width	635 mm
Height	616 mm
Weight	44500 g
