VIEWING PROFILE INFORMATION
Profile access
You can check the profile information.
1. Click [Status (
)] on the live screen.
2. The profile information screen is
displayed.
• Profile access : Show the information
of the newly added profile.
- Profile : Show the information of the
newly added codec.
- Bitrate(kbps) : Show both the actual
bit rate and the set bit rate.
- Framerate(fps) : Show both the
actual frame rate and the set frame
rate.
- ATC(%) : Show the ATC status.
- Concurrent users count : Show the number of concurrent users who access the
profile.
• Current users : Shows information on users accessing web viewer and displaying
monitoring video.
- Profile : Show the name of the profile accessed by the user.
- Bitrate(kbps) : Show the current bit rate.
- Network connection status : It shows whether the network is working fine.
- IP : Show the IP address of the current user.
M
`
To check information on the profile currently used, click [Status ( )] again to refresh it.
It takes a certain time for any changes to be applied.
setup screen
136_ setup screen

Samsung SNP-6320RH Specifications

General

Resolution	1920 x 1080
Connectivity Technology	Wired
Form Factor	Dome
Optical Zoom	32x
Digital Zoom	16x
Pan Range	360° endless
Ingress Protection	IP66
Vandal Proof	IK10
Video Compression	H.264, MJPEG
Signal-to-Noise Ratio	50 dB
Lens	Varifocal
Device Type	PTZ dome camera
Infrared Distance	150m (492ft)
Sensor Size	1/2.8 inch
Tilt Range	190°
Protocols	TCP/IP, UDP/IP, RTP/RTSP, HTTP, HTTPS, FTP, SMTP, DHCP, PPPoE, DDNS, NTP, UPnP, Bonjour, ONVIF
Power Source	AC 24V, PoE+
Network Interface	RJ45
Operating Temperature	-50°C ~ +55°C (-58°F ~ +131°F)
Sensor	CMOS
Minimum Illumination	0 Lux (IR LED on)
Power Supply	PoE+ (IEEE 802.3at), 24V AC
