Samsung SNP-6320RH User Manual

English _61
● SETUP SCREEN
SETUP
On the network, you can set up basic information on the camera, video and audio, network
events and system.
1. In the Live screen, click
[
Setup
(
)
]
.
2. The Setup screen appears.
J
`
The setting page for preview video requires the STW web viewer plug-in to be installed on the PC.
If it is not intalled properly, the installation page automatically apprears.
BASIC SETUP
Video profile
1. From the Setup menu, select the
<Basic ( )> tab.
2. Click <Video profile>.
3. Set the <Video profile connection
policy>.
• Keep connection when profile
setting is changed : Changing profile
properties that is used by existing
connection does not affect such
connection and remains with old
profile setup.
If not selected, changing a profile
used by an existing connection
resets such connection.
setup screen

Samsung SNP-6320RH Specifications

General

Resolution	1920 x 1080
Connectivity Technology	Wired
Form Factor	Dome
Optical Zoom	32x
Digital Zoom	16x
Pan Range	360° endless
Ingress Protection	IP66
Vandal Proof	IK10
Video Compression	H.264, MJPEG
Signal-to-Noise Ratio	50 dB
Lens	Varifocal
Device Type	PTZ dome camera
Infrared Distance	150m (492ft)
Sensor Size	1/2.8 inch
Tilt Range	190°
Protocols	TCP/IP, UDP/IP, RTP/RTSP, HTTP, HTTPS, FTP, SMTP, DHCP, PPPoE, DDNS, NTP, UPnP, Bonjour, ONVIF
Power Source	AC 24V, PoE+
Network Interface	RJ45
Operating Temperature	-50°C ~ +55°C (-58°F ~ +131°F)
Sensor	CMOS
Minimum Illumination	0 Lux (IR LED on)
Power Supply	PoE+ (IEEE 802.3at), 24V AC
