English _139
● APPENDIX
CAMERA WIRING
Control Signal Connection
•
RS-485 Communications
D+
D-
TXD+
TXD-
Camera Controller
•
RS-422 Communications
D+
D-
TXD+
TXD-
TXD+
TXD-
RXD+
RXD-
Camera Controller
Communications Cable
For the camera to communicate with the controller, a RS-485/422 communications line is
required.
J
`
A 30m or shorter length is recommended for the connection.
`
The communication cable is not enclosed with the camera.
