Samsung SNP-6320RH User Manual

50_ web viewer
web viewer
Item Description
h
Fix the resolution
Regardless of the resolution setup configured in the camera, it sets the resolution to
640x480. Press it again to switch back to the default resolution.
i
Full Screen Switch the current video to the maximum size of the monitor.
j
Capture Saves the snapshot as an image file in the .jpg format.
k
Manual recording
Users can save their video in the SD memory card or NAS on their own.
`
To take video manually, change the recording setting first. Refer to “Storage” for
how to set recording (page 108).
l
Audio/Microphone
Control
Enable Audio and Microphone are control the Audio volume.
`
Only the Audio volume can be controlled.
m
Alarm output Activate the Alarm Out port.
n
PTZ Control the pan/tilt/zoom operations of the camera.
o
Hide the context
menu
The left-corner context menu will disappear but only the menu icon.

Samsung SNP-6320RH Specifications

General

Resolution	1920 x 1080
Connectivity Technology	Wired
Form Factor	Dome
Optical Zoom	32x
Digital Zoom	16x
Pan Range	360° endless
Ingress Protection	IP66
Vandal Proof	IK10
Video Compression	H.264, MJPEG
Signal-to-Noise Ratio	50 dB
Lens	Varifocal
Device Type	PTZ dome camera
Infrared Distance	150m (492ft)
Sensor Size	1/2.8 inch
Tilt Range	190°
Protocols	TCP/IP, UDP/IP, RTP/RTSP, HTTP, HTTPS, FTP, SMTP, DHCP, PPPoE, DDNS, NTP, UPnP, Bonjour, ONVIF
Power Source	AC 24V, PoE+
Network Interface	RJ45
Operating Temperature	-50°C ~ +55°C (-58°F ~ +131°F)
Sensor	CMOS
Minimum Illumination	0 Lux (IR LED on)
Power Supply	PoE+ (IEEE 802.3at), 24V AC
