Samsung SNP-6320RH User Manual

56_ web viewer
web viewer
Name of time search screen and its function
Item Description
a
Time bar The section in the specific period is played by moving the time bar.
b
Search date setting
Set the search date using the calendar.
`
If there is data saved in your SD memory card or NAS on the day, it is
marked as a box on the calendar.
c
Speaker
To listen to a voice signal (if present) in the recorded video, then activate the
voice signal icon when you play it.
d
Screen optimization The camera image is converted to fit the Web browser window.
e
Fix the resolution
Regardless of the resolution setup configured in the camera, it sets
the resolution to 800x600. Press it again to switch back to the default
resolution.
f
Capture The current image is saved as a .jpg image file.
g
Full screen The current image is converted to cover the maximum size of the monitor.
f
b
a
h
i
c
d
e
g

Samsung SNP-6320RH Specifications

General

Resolution	1920 x 1080
Connectivity Technology	Wired
Form Factor	Dome
Optical Zoom	32x
Digital Zoom	16x
Pan Range	360° endless
Ingress Protection	IP66
Vandal Proof	IK10
Video Compression	H.264, MJPEG
Signal-to-Noise Ratio	50 dB
Lens	Varifocal
Device Type	PTZ dome camera
Infrared Distance	150m (492ft)
Sensor Size	1/2.8 inch
Tilt Range	190°
Protocols	TCP/IP, UDP/IP, RTP/RTSP, HTTP, HTTPS, FTP, SMTP, DHCP, PPPoE, DDNS, NTP, UPnP, Bonjour, ONVIF
Power Source	AC 24V, PoE+
Network Interface	RJ45
Operating Temperature	-50°C ~ +55°C (-58°F ~ +131°F)
Sensor	CMOS
Minimum Illumination	0 Lux (IR LED on)
Power Supply	PoE+ (IEEE 802.3at), 24V AC
