02. Operation and setting
02. Operation and setting
2-1. Function and name of the display
● This product is a digital recorder designed in dialogue type touch screen for easy use.
2
3
5
1
6
4
Cover (There are electric power switch, SD card insertion part,
Mini USB when the cover is opened.)
SDR100E electric switch
SD card insertion part
Lamp (The yellow lamp is on when the electric power is ON firstly.)
Screen display
Mini USB (For after sales service: User cannot use it.)
①
②
③
④
⑤
⑥
