[Fig. 3-1] Main screen
1 2 3 4
5 6
No. Main menu Description
Move to the Start/Stop for graph saving screen
Move to the data (Graph) searching screen stored
in the internal memory/SD card
Move to the function and operation setting screen
Move to the graph display option
(Graph recording and searching screen)
Move to the message setting screen
Move to the present time and reserve
operation setting (Start and Finish)
Move to the screen display setting and internal
memory/SD card capacity display screen
Move to the error and event history related screen
When ⑨, ⑩ is pressed in sequence, the password
box is activated to move to the system parameter
setting screen.
GRAPH RECORD
GRAPH SERACH
FUNCTION SET
GRAPH OPTION
CANNED MESSAGE
RESERVE SET
DISPLAY SET
ERROR HISTORY
SYSTEM SETTING
7 8
9
①
②
③
④
⑤
⑥
⑦
⑧
⑨, ⑩
10
