04. Graph recording
[Fig. 4-2] Screen in case of non saving the graph
(Display of sub menu bar)
[Fig. 4-3] Screen in case of saving the graph (White screen)
[Fig. 4-4] Bar graph screen
Symbol Description
Convert to [Fig. 3-1 Main screen
]
Convert to [Fig. 4-2 Screen in case of non saving the
graph]
Convert to [Fig. 4-4 Bar graph screen
]
Convert to [Fig. 4-5 Digital graph screen
]
[Fig. 4-6 Message input screen] is appeared and the
input or set image is shown
[Fig. 4-9 PV graph storage screen] is appeared and
the storage is started.
