Samwon Tech SDR100E Series User Manual

43
Parameter Initial value
RECORDING CYCLE
RECORD MEDIA
POWER STOP MODE
RESTRICT OF MAIN
BASIC SCREEN
USER PASSWORD
Channel #n PEN USING
Channel #n GRAPH DISPLAY HIGH
Channel #n GRAPH DISPLAY LOW
Channel #n PEN THICKNESS
Channel #n PV DISPLAY METHOD
Setting range Unit
0.5 sec, 1 sec, 2 sec, 5 sec, 10 sec, 20 sec, 30 sec, 1 min
MEM, SD, BOTH
STOP, HOT
UNUSE, USE
TREND, BAR, DIGIT
0~9999
UNUSE, USE
Channel #n.EU (-5.0~105.0%)
Channel #n.DISPLAY < Channel #n.DISPLAY
1 PIXEL, 3 PIXEL
TAG, BAR
ABS
ABS
ABS
ABS
ABS
ABS
ABS
Channel #n.EU
Channel #n.EU
ABS
ABS
1 sec
MEM
STOP
UNUSE
TREND
0
Use
Channel #n.EU(100%)
Channel #n.EU(0%)
1 PIXEL
TAG
※ #n : 1 ~ 12
06. Function setting
