Parameter Setting range Unit Initial value
Channel #n ALARM#m TYPE
OFF, AL.HI, AL.LO, AL.IN, AL.OUT, AL.USL,
AL.DSL, AL.DVI, AL.DVO, SNR.OPN
ABS OFF
Channel #n ALARM#m POINT
CHANNEL #n.EU(-5.0~105.0%) CHANNEL #n.EU
CHANNEL#n.EU(100.0%) /
CHANNEL#n.EU(0.0%)
Channel #n ALARM#m HIGH POINT
CHANNEL #n.EU(-5.0~105.0%) CHANNEL #n.EU CHANNEL #n.EU(0.0%)
Channel #n ALARM#m LOW POINT
Channel #n ALARM#m HYSTERESIS
CHANNEL #n.EUS(0.0~50.0%) CHANNEL #n.EUS CHANNEL #n.EUS(0.5%)
Channel #n ALARM#m DELAY TIME
0.00~99.59 (MIN.SEC) ABS 00.00
Channel #n ALARM#m RELAY
0 ~ 12 ABS 0
Channel #n ALARM#m RELAY CHANNEL #n.EUS(0.0~50.0%) CHANNEL #n.EUS CHANNEL #n.EUS(0.0%)
Channel #n ALARM#m UP SLOPE HIGH CHANNEL #n.EUS(0.0~50.0%) CHANNEL #n.EUS CHANNEL #n.EUS(0.0%)
Channel #n ALARM#m DOWN SLOPE LOW 1MIN, 1HOUR ABS 1MIN
Channel #n ALARM#m SAMPLE NUMBER 0 ~ 32 ABS 1
Channel #n ALARM#m CHANNEL 0 ~ 12 ABS 0
Channel #n ALARM#m DEVIATION CHANNEL #n.EUS(0.0~50.0%) CHANNEL #n.EUS CHANNEL #n.EUS(0.0%)
※ #n : 1 ~ 12
※ #m : 1 ~ 4
