14
※T.EU:Rangeofinputdatafortemperaturesensor
※H.EU:Rangeofinputdataforhumiditysensor
※Referto[Engineeringunits]
[Fig.3-4]ScreenofInputforhumiditysettingaboutoperation
References
▶Theinputforsetvaluefortemperatureisactivatedwhen
buttonistouched[Fig.3-3creenofInput
fortemperaturesettingaboutoperationtemperature]
▶Theinputforsetvalueforhumidityisactivatedwhen
buttonistouched.[Fig.3-4ScreenofInput
forhumiditysettingaboutoperation]
▶Whentheinputofsetdataoftemperatureandhumidityare
completed,operatethestationaryoperationbyselecting.
Parameter Initial value
Tempsettingdata(SP)
Humisettingdata(SP)
Setting range Unit
T.EU(0.00~100.00%)
H.EU(0.0~100.0%)
T.EU
H.EU
T.EU(0.00%)
H.EU(0.0%)
[Fig.3-3]ScreenofInputfortemperaturesettingabout
operationtemperature
