S&C IntelliCap 2000 User Manual

Figure 12. Grounding the IntelliCap 2000 control enclosure.
Installing the Capacitor Control
Ground lug
IntelliCap 2000
®
Automatic Capacitor Control
Junction box connection
to control
Neutral sensor connection
to junction box
Single-phase current sensor
Current sensor
connection to
junction box
Bank switch
Switch close/open
cable
Current sensor connection
to common neutral
VT sensing/power
cable
Single-phase voltage
transformer
Cap bank connection
to common neutral
Neutral sensor
Common neutral
Junction
box
S&C Instruction Sheet 1024-510 13
