S&P NEMBUS 210 User Manual

32
INPUT REGISTERS (Read only)
Modbus Adress Register Values Description Default Data type
30005 Communication error
0 No error 16 bit word
1 Remote controller 16 bit word
4 Modbus RTU 16 bit word
30006 Defrost status
0 Not active 16 bit word
1 Active (fireplace defrost) 16 bit word
2 Active (with pre-heater) 16 bit word
3
Active (unbalanced
airflows)
16 bit word
30026 Extract air temperature -500…+600 dºC dºC 16 bit word
30027 Exhaust air temperature -500…+600 dºC dºC 16 bit word
30026 Outdoor air temperature -500…+600 dºC dºC 16 bit word
30026 Supply air temperature -500…+600 dºC dºC 16 bit word
30030 Relative humidity extract air 0-100% % 16 bit word
30031 Relative humidity exhaust air 0-100% % 16 bit word
30032 Relative humidity outdoor air 0-100% % 16 bit word
30033 Relative humidity supply air 0-100% % 16 bit word
30060
Control voltage extract
motor
0-100 dV 16 bit word
30061 Control voltage supply motor 0-100 dV 16 bit word
30062 RPM extract motor 0-5000 rpm rpm 16 bit word
30063 RPM supply motor 0-5000 rpm rpm 16 bit word
30064 Bypass damper position
0 Closed 16 bit word
1 Open 16 bit word
2 Error 16 bit word
30091 Actual working mode
0 Snooze mode 16 bit word
1 Low speed 16 bit word
2 Medium speed 16 bit word
3 High speed 16 bit word
4 Boost 16 bit word
5
Auto mode (humidity
sensor)
16 bit word
6 Auto mode (VOC sensor) 16 bit word
7
Auto mode (0-10V
control)
16 bit word
8 Boost in auto mode 16 bit word
9 Weekly program 1 16 bit word
10 Weekly program 2 16 bit word
11 Weekly program 3 16 bit word
12 Weekly program 4 16 bit word
HOLDING REGISTERS (Read/Write)
Modbus Adress Register Values Description Default Data type
40001 Modbus slave adress 1-247 1 16 bit word
40002 Baudrate
48 4800
192
16 bit word
96 9600 16 bit word
192 19200 16 bit word
384 38400 16 bit word
40003 Modbus parity
0 EVEN
0
16 bit word
1 ODD 16 bit word
2 No parity (2 stop bits) 16 bit word
40049 Day 1-31 Day (clock) Set from factory 16 bit word
40050 Month 1-12 Month (clock) Set from factory 16 bit word
40051 Year 2016-2100 Year (clock) Set from factory 16 bit word
40052 Hour 0-23 Hour (Clock) Set from factory 16 bit word
40053 Minutes 0-59 Minutes (Clock) Set from factory 16 bit word
40054 Seconds 0-59 Seconds (Clock) Set from factory 16 bit word
40057 Manual by-pass timer 1-8 h Manual by-pass timer 8 h 16 bit word
40064 Min ODA for by-pass 120…200 dºC
Minimum outdoor
temperature for by-pass
activation
130 dºC 16 bit word
40066 Min ETA for by-pass 210-300 dºC
Minimum extract
temperature for by-pass
activation
230 dºC 16 bit word
