Sandpiper S20 User Manual

520-202-000 9/03 Model S20 Non-Metallic Design Level 2 Page 13
Composite Repair Parts List
ITEM PART NUMBER DESCRIPTION QTY
1 031-140-000 Air Valve Assembly 1
031-140-002 Air Valve Assembly w/ PTFE coated Hardware 1
031-141-000 Air Valve Assembly (No Encapsulated Muffler) 1
2 095-093-000 Pilot Valve Assembly 1
3 050-038-354 Ball, Check 4
050-038-600 Ball, Check 4
4 114-021-156 Intermediate Assembly 1
114-021-307 Intermediate Assembly 1
114-021-309 Intermediate Assembly 1
114-021-332 Intermediate Assembly 1
5 115-132-080 Bracket, Mounting 2
115-132-305 Bracket, Mounting 2
115-132-306 Bracket, Mounting 2
115-132-333 Bracket, Mounting 2
6 132-019-360 Bumper, Diaphragm 2
7 135-032-506 Bushing, Plunger 2
8 165-099-156 Cap, Air Inlet 1
165-099-307 Cap, Air Inlet 1
165-099-309 Cap, Air Inlet 1
165-099-332 Cap, Air Inlet 1
9 170-052-115 Capscrew, Hex HD 3/8-16 x 2.25 4
170-052-308 Capscrew, Hex HD 3/8-16 x 2.25 4
10 170-055-115 Capscrew, Hex HD 1/2-13 x 2.50 16
170-055-308 Capscrew, Hex HD 1/2-13 x 2.50 16
11 170-068-115 Capscrew, Hex HD 1/2-13 x 1.75 8
170-068-308 Capscrew, Hex HD 1/2-13 x 1.75 8
12 170-095-115 Capscrew, Soc HD 1/2-13 x 3.00 8
170-095-308 Capscrew, Soc HD 1/2-13 x 3.00 8
13 170-110-115 Capscrew, Soc HD 5/8-11 x 3.00 16
170-110-308 Capscrew, Soc HD 5/8-11 x 3.00 16
14 171-004-115 Capscrew, Flat HD 1/2-13 X 1.25 6
15 171-053-115 Capscrew, Soc HD 3/8-16 X 2.75 4
171-053-308 Capscrew, Soc HD 3/8-16 X 2.75 4
16 196-148-156 Chamber, Inner 2
196-148-307 Chamber, Inner 2
196-148-309 Chamber, Inner 2
196-148-332 Chamber, Inner 2
17 196-150-520 Chamber, Outer 2
196-150-552 Chamber, Outer 2
18 286-074-354 Diaphragm 2
19 286-075-600 Diaphragm, Overlay 2
20 312-102-520 Elbow 4
312-102-552 Elbow 4
21 360-090-360 Gasket, Air Inlet 1
22 360-091-360 Gasket, Inner Chamber 2
23 360-092-360 Gasket, Pilot Valve 1
24 360-093-360 Gasket, Main Air Valve 1
25 518-132-520 Manifold 2
518-132-520E Manifold, 50mm DIN 2
518-132-552 Manifold 2
518-132-552E Manifold, 50mm DIN 2
26 545-008-110 Nut, Hex 1/2-13 32
545-008-308 Nut, Hex 1/2-13 32
27 545-009-110 Nut, Hex 5/8-11 16
545-009-308
Nut, Hex 5/8-11 16
2
8 560-001-360 O-ring 2
29 612-179-520 Assembly, Outer Diaphragm Plate 2
612-179-552 Assembly, Outer Diaphragm Plate 2
30 612-158-150 Assembly, Inner Diaphragm Plate 2
31 620-017-115 Plunger, Actuator 2
32 670-046-520 Retainer, Ball 4
670-046-552 Retainer, Ball 4
33 685-050-120 Rod, Diaphragm 1
34 685-053-115 Rod, Support 2
685-053-308 Rod, Support 2
35 720-010-375 Seal, Diaphragm Rod 2
36 720-038-600 Seal, Manifold Spacer 8
37 720-041-600 Seal, Check Valve Assembly 8
38 722-075-520 Seat, Check Valve 4
722-075-552 Seat, Check Valve 4
39 770-056-520 Spacer, Manifold 4
770-056-552 Spacer, Manifold 4
40 901-046-115 Washer, Flat 1/2" 60
901-046-308 Washer, Flat 1/2" 60
41 901-047-115 Washer, Flat 5/8" 32
901-047-308 Washer, Flat 5/8" 32
42 901-048-115 Washer, Flat 3/8" 8
901-048-308 Washer, Flat 3/8" 8
43 538-035-555 Nipple, Pipe 1" NPT Close 1
44 530-027-000 Muffler 1
NOT SHOWN:
535-069-000 Nameplate
ITEM PART NUMBER DESCRIPTION QTY
