520-202-000 9/03 Model S20 Non-Metallic Design Level 2 Page 2
Check Diaphragm/ Check Non-Wetted Shipping
Model Pump Pump Valve Design Wetted Check Valve Valve Material Porting Pump Pump Kit Weight
Brand Size Type Level Material Materials Seat Options Options Style Options Options lbs. (kg)
S20B2P1PQAS000. S 20 B 2 P 1 P Q A S 0 00. 117 (53)
S20B2K1KQAS000. S 20 B 2 K 1 K Q A S 0 00. 117 (53)
S20B2P2PQAS000. S 20 B 2 P 2 P Q A S 0 00. 151 (68)
S20B2K2KQAS000. S 20 B 2 K 2 K Q A S 0 00. 151 (68)
S20B2P3PQAV000. S 20 B 2 P 3 P Q A V 0 00. 148 (67)
S20B2K3KQAV000. S 20 B 2 K 3 K Q A V 0 00. 189 (86)
S20B2P4PQAV000. S 20 B 2 P 4 P Q A V 0 00. 148 (67)
S20B2K4KQAV000. S 20 B 2 K 4 K Q A V 0 00. 189 (86)
Pump Brand
S=SANDPIPER
®
Pump Size
20=2"
Check Valve Type
B=Ball
Design Level
2= Design Level 2
Wetted Material
K= PVDF
P= Polypropylene
Diaphragm Check Valve Materials
1= Santoprene/Santoprene
2= PTFE-Santoprene Backup/PTFE
3= PTFE Pumping, PTFE-Santoprene
Backup Driver/PTFE
4= Santoprene Pumping, Santoprene
Driver/Santoprene
Check Valve Seat
K= PVDF
P= Polypropylene
Non-Wetted Material Options
A= Painted Aluminum
J= Painted Aluminum PTFE
Q= Epoxy Coated Aluminum
K= PTFE Coated Aluminum
L= PTFE Coated Aluminum with
PTFE Coated Hardware
R= Epoxy Coated Aluminum with
PTFE Coated Hardware
Porting Options
A= ANSI Flange
D=DIN Flange
7= Dual Porting (ANSI)
8= Top Dual Porting (ANSI)
9= Bottom Dual Porting (ANSI)
Pump Style
D=RuppGUARD™ with Electronic
Leak Detection (110V)
E= RuppGUARD™ with Electronic
Leak Detection (220V)
M=RuppGUARD™ with Mechanical
Leak Detection
S=Standard
V= RuppGUARD™ with Visual
Leak Detection
Pump Options
0= None
1= 3M Muffler
2= Mesh Muffler
3= High temperature Air Valve
w/Encapsulated Muffler
4= High temperature Air Valve
w/3M Muffler
5= High temperature Air Valve
w/Mesh Muffler
S20 Non-Metallic · Design Level 2· Ball Valve
Explanation of Pump Nomenclature
Kit Options
00.=None
P0.=0-30VDC Pulse Output Kit
P1.=Intrinsically-Safe 10-30VDC
Pulse Output Kit
P2.=110/120 or 220/240VAC
Pulse Output Kit
P3.=Intrinsically-Safe 110/120VAC
Pulse Output Kit
P4.=Intrinsically-Safe 220/240VAC
Pulse Output Kit
E0.=Solenoid Kit with 24VDC Coil
E1.=Solenoid Kit with 24VDC
Explosion-Proof Coil
E2.=Solenoid Kit with 24VAC/12VDC
Coil
E3.=Solenoid Kit with 24VAC12VDC
Explosion-Proof Coil
E4.=Solenoid Kit with 110VAC Coil
E5.=Solenoid Kit with 110VAC
Explosion-Proof Coil
E6.=Solenoid Kit with 220VAC Coil
E7.=Solenoid Kit with 220VAC
Explosion-Proof Coil
SP.=Stroke Indicator Pins
