16
Connections
GB
Connecting a Coaxial Audio Receiver
For better sound quality, you may want to play the audio through your multi-channel audio receiver.
1. Use an audio cable to connect the TV’s COAXIAL output socket to an
external audio receiver’s audio coaxial input socket.
2. Plug the connected devices into the mains socket before switching
on the POWER ON/OFF switch which is located at the bottom under
the frame.
3. Press the
button on the bottom panel of the TV or the POWER
button on the remote control to turn on your TV.
4. Press the SOURCE button on the remote control to display the Input
Source. Use the
buttons to select any desired input source and
then press the OK button to confirm.
Rear Left side of TV
Audio Cable
(not included)
Audio Receiver
Connecting Earphones
Connect your earphones to the TV’s socket.
Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Rear Left side of TV
HDMI1 HDMI2 VGA Y/Pb/Pr A/V IN HP USB
Common Interface
PC
audio
Earphones Cable
(not included)
The TV’s volume control will have no effect. You may control the
audio level via the Audio Receiver.
Long-term exposure to loud music may cause
hearing damage. It is best to avoid extreme
volume when using earphones, especially for
extended periods.
S24LED11_IB_111014_Zell.indd 16 14/10/2011 3:36 PM
