Front / Top / Side View and Controls
Item Description
1 POWER ON/OFF Switch on the POWER ON/OFF switch to turn the TV to standby mode.
2 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
3
Switches the TV on from standby mode.
Switches the TV back to standby mode.
4 POWER LED
Illuminates green when the TV is turned on. Illuminates red when the TV is in standby
mode.
5 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
6 Disc Slot
Insert the disc with the label side facing the rear of the TV (12 cm discs only. Don't
insert 8 cm discs)
CH+CH– I/O
3 4
5
6
2
1
OFF
ON
S24LED11_IB_111014_Zell.indd 7 14/10/2011 3:36 PM
