Parts and functions
Remote sensor
POWER indicator
RF (ANT) IN jack
HEADPHONE jack
PC IN jacks
PC AUDIO IN jack
Front Top
Rear side
To display the menu screen.
Press MENU button to display the menu screen.
CHANNEL ▲/▼ buttons and VOLUME +/– buttons can be used to select the desired setting during the menu
screen operations.
COMPONENT IN jacks
VOLUME
+/– buttons
CHANNEL
C/D buttons
MENU
button
INPUT
button
POWER
button
AC INPUT jack
S-VIDEO IN jack
AUDIO (L/R) IN
jacks
COAXIAL DIGITAL AUDIO OUT jack
VIDEO IN Jack
