SANY SY60C - Working Range

SPECIFICATIONS
6-3
SY60C Excavator OMM
Working Range
0002893
Figure 6-2
Item Description Dimensions
1 Maximum cutting height 19 ft. (5790 mm)
2 Maximum height at minimum swing radius 14 ft. 8.76 in. (4.49 m)
3 Maximum dumping height 13 ft. 4 in. (4.06 m)
4 Minimum swing radius 8 ft. 5 in. (2.55 m)
5 Maximum dozer raising height 1 ft. 3.12 in. (385 mm)
6 Maximum dozer lowering depth 1 ft. 2.88 in. (380 mm)
7 Maximum reach at ground level 20 ft. 8.76 in. (6.32 m)
8 Maximum vertical wall digging depth 10 ft. 5.16 in. (3.18 m)
9 Maximum digging depth 13 ft. (3.95 m)
9
8
1
3
4
5
7
6
2
