3-18
MACHINE CONTROLS
SY60C Excavator OMM
Horn Button
0002863
Figure 3-24
The horn button (1) is on top of the right joystick. Press
the horn button to sound the horn.
Auxiliary Hydraulic Switch
0002863
Figure 3-25
The auxiliary hydraulic switch (1) is on top of the right
joystick. The auxiliary hydraulic switch is used for
optional one-way or two-way flow equipment.
Work Light Switch
0002758
Figure 3-26
The work light switch (1) turns the work lights on and off.
0002759
Figure 3-27
There are three work lights:
• One work light (2) on the boom.
0002760
Figure 3-28
• Two work lights (3) on the cab roof.
Windshield Wiper Switch
0002758
Figure 3-29
NOTICE!
Before cleaning a dry windshield, press the
windshield washer switch to spray washer fluid
on the windshield to prevent damage to the wiper
blade.
1
1
1
2
3
3
1
