-94-
Control Port Functions
PIN PORT NAME DESCRIPTION I/O
1 DVss DVss - -
2 P1 DDC_SW1 DVI/HDC DDC Switch 1 Normal: L, Connect: H O
3 P2 DDC_SW2 Analog DDC Switch 2 Normal: L, Connect: H O
4 P3 PC1/PC2_SW PC1 Analog / PC2 AnalogSwitch H: PC1, L: PC2 O
5 P4 SIRST Sil169 Reset H-L-H O
6 P5 DVI_HPD DVI Hot Plug Detection O
7 P6 HDCP_IIC_SW HDCP Authentication IIC Bus Switch, L: HDCP H: Others O
8 P7 PJ_UPDATE PJ-Net Forced Write Mode, Normal: H O
9 P8 NET_H/L PJNet Command Request O
10 DVdd25 DVdd25 - -
11 DVss DVss - -
12 DVdd33 DVdd33 - -
13 A6 A6 Address 6 I
14 A5 A5 Address 5 I
15 A4 A4 Address 4 I
16 A3 A3 Address 3 I
17 A2 A2 Address 2 I
18 A1 A1 Address 1 I
19 A0 A0 Address 0 I
20 XCS XCS0 Chip Select I
21 XRD XRD Read Enable I
22 XWR XWR Write Enable I
23 RSTPOL RSTPOL Polarity Select for Reset I
24 DVss DVss - -
25 DVdd33 DVdd33 - -
26 D7 D7 Data Bus 7 I/O
27 D6 D6 Data Bus 6 I/O
28 D5 D5 Data Bus 5 I/O
29 D4 D4 Data Bus 4 I/O
30 D3 D3 Data Bus 3 I/O
31 D2 D2 Data Bus 2 I/O
32 D1 D1 Data Bus 1 I/O
33 D0 D0 Data Bus 0 I/O
34 WAKEUP WAKEUP Wakeup O
35 DVss DVss - -
36 RST RST Reset Input, Active:H I
37 DVdd33 DVdd33 - -
38 XI XI XTAL IN I
39 XO XO XTAL OUT O
40 DVss DVss - -
41 DVdd33 DVdd33 - -
42 XCS1 XCS1 Ext. Chip Select O
43 XSTDBYEN XSTDBYEN Standby Mode On/Off I
44 DVdd25 DVdd25 - -
45 XINVALID XINVALID Serial Port Enable I
46 DVss DVss - -
47 XINT XINT Level Output O
48 P21 SIPDO DVI Output Power Down Mode L: Power Down O
49 P22 PROG_I/O Configuration Start Pin L: Fixed O
50 P23 LENS_LR_SW LensMoving Switch O
51 P24 STB_I/O FPGA Chip Select (Strobe) O
52 P25 R/C_CTL1 Rear-RC Selection Switch, L: Rear O
53 P26 R/C_CTL0 Front-RC Selection Switch, L: Front O
54 P27 USB_VBUS USB VBUS I
Parallel I/O Expander Port Functions (TE7783, IC1801)
PIN PORT NAME DESCRIPTION I/O
257 K28 - Not used -
152 K29 Focus+ Focus+ [H: Active, L: Stop] O
39 K30 Zoom- Zoom- [H: Active, L: Stop] O
445 M26 CHO_RXD CHO_RXD I
356 M27 CHO_TXD CHO_TXD O
67 AK22 ADC0 Not used AI
178 AJ22 KEY1 Key Input1 AI
281 AH22 KEY2 Key Input2 AI
68 AK21 KEY3 Key Input3 AI
179 AJ21 OPTION1 Option SW (Not used) AI
282 AH21 OPTION2 Option SW (Not used) AI
69 AK20 AI
180 AJ20 OPTION3 Option SW (Brand) AI
65 AK24 FAN_DAC1_PW Analog Output for Fan Control1 AO
176 AJ24 FAN_DAC2_PW Analog Output for Fan Control2 AO
66 AK23 FAN_DAC3_PW Analog Output for Fan Control3 AO
177 AJ23 PW_DAC Not used AO
To Next Page
