Sanyo PLC-SW30 Service Manual

-28-
300 Position (Vertical) 60Hz PIXEL N/A 384 N/A
301 Expand Ratio (Vertical) 50Hz PIXEL N/A 5 Video and S-Video mode only
302 Expand Ratio (Horizontal) 50Hz PIXEL N/A 24 Progressive OFF
303 Position (Horizontal) 50Hz PIXEL N/A 519
304 Position (Vertical) 50Hz PIXEL N/A 383
305 Expand Ratio (Vertical) 480i PIXEL N/A 1 N/A For Component 480i mode
306 Expand Ratio (Horizontal) 480i PIXEL N/A 17 N/A Progressive OFF
307 Position (Horizontal) 480i PIXEL N/A 513 N/A
308 Position (Vertical) 480i PIXEL N/A 384 N/A
309 Expand Ratio (Vertical) 575i PIXEL N/A 5 N/A For Component 575i mode
310 Expand Ratio (Horizontal) 575i PIXEL N/A 24 N/A Progressive OFF
311 Position (Horizontal) 575i PIXEL N/A 519 N/A
312 Position (Vertical) 575i PIXEL N/A 383 N/A
313 Expand Ratio (Vertical) 480p PIXEL N/A 10 N/A For Component 480p mode
314 Expand Ratio (Horizontal) 480p PIXEL N/A 32 N/A
315 Position (Horizontal) 480p PIXEL N/A 517 N/A
316 Position (Vertical) 480p PIXEL N/A 382 N/A
317 Expand Ratio (Vertical) 575p PIXEL N/A 18 N/A For Component 575p mode
318 Expand Ratio (Horizontal) 575p PIXEL N/A 29 N/A
319 Position (Horizontal) 575p PIXEL N/A 517 N/A
320 Position (Vertical) 575p PIXEL N/A 393 N/A
321 Expand Ratio (Vertical) 720p PIXEL 9 N/A 10 N/A For Component and RGB 720p mode
322 Expand Ratio (Horizontal) 720p PIXEL 15 N/A 14 N/A
323 Position (Horizontal) 720p PIXEL 513 N/A 525 N/A
324 Position (Vertical) 720p PIXEL 385 N/A 385 N/A
325 Expand Ratio (Vertical) 1035i PIXEL 5 N/A 5 N/A For Component mode and RGB HDTV 1035i
326 Expand Ratio (Horizontal) 1035i PIXEL 23 N/A 23 N/A
327 Position (Horizontal) 1035i PIXEL 510 N/A 519 N/A
328 Position (Vertical) 1035i PIXEL 382 N/A 382 N/A
329 Expand Ratio (Vertical) 1080i PIXEL 7 N/A 7 N/A For Component mode and RGB HDTV 1080i
330 Expand Ratio (Horizontal) 1080i PIXEL 22 N/A 23 N/A
331 Position (Horizontal) 1080i PIXEL 508 N/A 517 N/A
332 Position (Vertical) 1080i PIXEL 382 N/A 383 N/A
333 Expand Ratio (Vertical) 60Hz PIXEL 7 N/A For RGB NTSC 480i
334 Expand Ratio (Horizontal) 60Hz PIXEL 36 N/A
335 Position (Horizontal) 60Hz PIXEL 517 N/A
336 Position (Vertical) 60Hz PIXEL 383 N/A
337 Expand Ratio (Vertical) 50Hz PIXEL 20 N/A For RGB PAL 575i
338 Expand Ratio (Horizontal) 50Hz PIXEL 40 N/A
339 Position (Horizontal) 50Hz PIXEL 515 N/A
340 Position (Vertical) 50Hz PIXEL 384 N/A
341 Expand Ratio (Vertical) 50Hz PIXEL 7 N/A 7 N/A For 1080i_50Hz and RGB HDTV 1080i_50Hz
342 Expand Ratio (Horizontal) 50Hz PIXEL 14 N/A 14 N/A
343 Position (Horizontal) 50Hz PIXEL 517 N/A 522 N/A
344 Position (Vertical) 50Hz PIXEL 384 N/A 384 N/A
345 Expand Ratio (Vertical) SCART PIXEL 5 N/A For RGB SCART
346 Expand Ratio (Horizontal) SCART PIXEL 23 N/A Progressive OFF
347 Position (Horizontal) SCART PIXEL 518 N/A
348 Position (Vertical) SCART PIXEL 383 N/A
349 Expand Ratio (Vertical) 60Hz PIXEL N/A 2 N/A For Video and S-Video only
350 Expand Ratio (Horizontal) 60Hz PIXEL N/A 17 N/A Progressive ON
351 Position (Horizontal) 60Hz PIXEL N/A 513 N/A
352 Position (Vertical) 50Hz PIXEL N/A 383 N/A
353 Expand Ratio (Vertical) 50Hz PIXEL N/A 5
354 Expand Ratio (Horizontal) 50Hz PIXEL N/A 23
355 Position (Horizontal) 50Hz PIXEL N/A 519
356 Position (Vertical) 50Hz PIXEL N/A 383
357 Expand ratio (Vertical) 480i PIXEL N/A 2 N/A For Component 480i mode
358 Expand Ratio (Horizontal) 480i PIXEL N/A 17 N/A Progressive ON
359 Position (Horizontal) 480i PIXEL N/A 513 N/A
360 Position (Vertical) 480i PIXEL N/A 383 N/A
361 Expand ratio (Vertical) 575i PIXEL N/A 5 N/A For Component 575i mode
362 Expand Ratio (Horizontal) 575i PIXEL N/A 24 N/A Progressive ON
363 Position (Horizontal) 575i PIXEL N/A 519 N/A
364 Position (Vertical) 575i PIXEL N/A 383 N/A
365 Expand ratio (Vertical) SCART PIXEL 5 N/A For RGB SCART
Electrical Adjustments
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
