Sanyo PLC-SW30 Service Manual

-29-
Electrical Adjustments
366 Expand Ratio (Horizontal) SCART PIXEL 23 N/A For RGB SCART
367 Position (Horizontal) SCART PIXEL 518 N/A Progressive ON
368 Position (Vertical) SCART PIXEL 383 N/A
369 Expand ratio (Vertical) 60Hz PIXEL 10 N/A For RGB 480p
370 Expand Ratio (Horizontal) 60Hz PIXEL 33 N/A
371 Position (Horizontal) 60Hz PIXEL 508 N/A
372 Position (Vertical) 60Hz PIXEL 375 N/A
373 Expand ratio (Vertical) 50Hz PIXEL 21 N/A For RGB 575p
374 Expand Ratio (Horizontal) 50Hz PIXEL 30 N/A
375 Position (Horizontal) 50Hz PIXEL 512 N/A
376 Position (Vertical) 50Hz PIXEL 385 N/A
400 Gamma Shift Combination ON/OFF 1 0: each source separate / 1: PC source only separate
401 PC Frame Lock OFF 0 0: ON for all source / 1: OFF at PC
402 Auto Grayscale black control start point 31
403 Auto Grayscale black control limit point 16
404 Auto Grayscale black control target point 0
405 Auto Grayscale white control start point 33
406 Auto Grayscale white control limit point 56
407 Auto Grayscale white control target point 0
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
