Sanyo PLC-SW30 User Manual

35
Video Input
Screen Size Adjustment
This projector has a picture screen resize function, which enables you to display the desirable image size.
Press MENU button to display the On-Screen Menu. Press
Point
7 8 buttons to move the red frame pointer to Screen
Menu icon.
Press Point d button and move the red frame pointer to the
function that you want to select and then press SELECT button.
1
2
Note: The Screen Menu cannot be operated when
“720p,” “1035i,” or “1080i” is selected on the
AV System Menu( ☞ P32 ).
Move the red frame to
the function and press
SELECT button.
SCREEN MENU
Screen Menu icon
Provides image at a wide screen ratio of 16 : 9.
Wide
Provides image at a normal video aspect ratio of 4 : 3.
Normal
To store the adjustment data, move the red frame pointer to
Store icon and press SELECT button. Image Level Menu will
appear. Move the red frame pointer to the Image Level 1 to 4
and then press SELECT button.
Image Level Menu
Move the red frame
pointer to the image
icon to be set and
then press SELECT
button.
Store icon
Reset all adjustment to previous figure.
Reset
Store
Closes the Image Menu.
Quit
When this function is "ON", it automatically enhances contrast of
bright and dark part of image.
Auto grayscale
Interlace video signal can be displayed in a progressive picture.
Off ···· Not activated.
L1 ···· Select “L1” for an active picture.
L2 ···· Select “L2” for a still picture.
progressive
Note : The Progressive cannot be selected when 1080i, 1035i, 480p, 575p,
or 720p is selected.

Sanyo PLC-SW30 Specifications

General

Native aspect ratio	4:3
Projection distance	- m
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	3LCD
Contrast ratio (typical)	300:1
Screen size compatibility	34 - 200 \
Projector native resolution	SVGA (800x600)
Keystone correction, horizontal	20 °
Lamp type	UHP
Lamp power	150 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	2500 h
RMS rated power	0.8 W
Number of built-in speakers	1
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Power consumption (typical)	244 W
Power consumption (PowerSave)	169 W
Focus	Manual
Throw ratio	1.6 - 1.9:1
Focal length range	- mm
Aperture range (F-F)	1.6 - 1.8
HDCP	-
Noise level	- dB
Dot clock scanning frequency	100 MHz
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	800 x 600 (SVGA)
USB connector type	USB Type-B
HDMI ports quantity	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Placement	Desktop
Product type	Standard throw projector
Product color	Black, White
Cables included	AC, VGA
Remote control type	IR

Weight and Dimensions

Depth	190 mm
Width	270 mm
Height	78 mm
Weight	2100 g
