Sanyo PLC-XL51A Service Manual

Electrical Parts List
KV7-XL51A00
- 100 -
Key. No. Part No. Description
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q6907 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q7801 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q7841 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q7871 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q7891 305 217 5019 TR RN1117 TE85L
Q7892 305 217 5019 TR RN1117 TE85L
Q8702 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q8756 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q890 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q9604 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC1293 309 439 8919 IC TC7WH125FU
IC1302 310 479 4004 IC TC7WBD125AFK
IC1303 310 479 4004 IC TC7WBD125AFK
IC1351 409 699 6516 IC TA48S00AF
IC1361 409 699 6516 IC TA48S00AF
IC1371 309 531 6229 IC FA7701V-TE1
IC1381 309 553 4712 IC PQ070XZ02ZP
IC1391 310 538 4907 IC 24LC64T-I/SNG
IC1392 309 439 8919 IC TC7WH125FU
IC1401 410 628 4906 IC TC7WBL125AFK(T5L,F
IC1402 410 628 4906 IC TC7WBL125AFK(T5L,F
IC1403 309 642 8713 IC TC7SA32FU(TE85L,F)
IC1404 309 330 2511 IC TC7SH04FU-(TE85L)
IC1441 409 699 6516 IC TA48S00AF
IC1451 409 699 6516 IC TA48S00AF
IC1491 409 699 6516 IC TA48S00AF
IC1802 309 671 7817 IC TE7783APF
IC1821 409 699 6516 IC TA48S00AF
IC1875 310 362 6504 IC TC74LCX541FT
IC213 309 487 5727 IC TC7SZ125FU
IC301 309 670 8419 IC PW190-10L
IC302 309 487 5727 IC TC7SZ125FU
IC303 309 487 5727 IC TC7SZ125FU
IC3501 309 431 4424 IC M62334FP-DF5Q
IC3801 309 652 0714 IC HIN202EIBNZ-T
IC401 409 680 7317 IC CXD3540AGB
IC4011 310 358 1506 IC TC74HC4053AFT(EL)
IC4021 309 400 9112 IC TC7SET08FU-(TE85L)
IC4022 309 400 9112 IC TC7SET08FU-(TE85L)
IC4581 409 699 6516 IC TA48S00AF
IC4590 409 698 1017 IC NJU7704F3-42(TE1)
IC4591 409 699 6516 IC TA48S00AF
IC4801 309 464 1411 IC TC74ACT14FT
IC4891 309 404 7213 IC TC7SET00FU-(TE85L)
IC5001 309 564 1519 IC NJW1141M(TE2)
IC5041 310 405 9301 IC TDA7056AT/N2
IC5201 309 530 7217 IC AN5870SB-E1V
IC5302 309 439 8919 IC TC7WH125FU
IC5621 409 699 6516 IC TA48S00AF
IC5641 309 461 7822 IC PQ20WZ11
IC5642 309 531 6229 IC FA7701V-TE1
IC5701 309 461 7822 IC PQ20WZ11
IC5751 309 531 6229 IC FA7701V-TE1
IC6201 309 462 0327 IC 24LC21AT/SN
IC6202 310 517 6809 IC TC74LVX4053FT
IC6211 309 462 0327 IC 24LC21AT/SN
IC6212 310 517 6809 IC TC74LVX4053FT
IC6942 309 334 0137 IC TC7W125FU
IC6961 309 439 8919 IC TC7WH125FU
IC6962 309 439 8919 IC TC7WH125FU
IC7201 410 631 4504 IC EP2C5F256C8N
IC7261 409 699 6516 IC TA48S00AF
IC7271 409 699 6615 IC BD7820FP
IC7281 309 439 8919 IC TC7WH125FU
IC7282 309 439 8919 IC TC7WH125FU
IC7801 309 461 7822 IC PQ20WZ11
IC7821 309 461 7822 IC PQ20WZ11
IC7841 309 461 7822 IC PQ20WZ11
IC7861 309 461 7822 IC PQ20WZ11
IC7871 309 461 7822 IC PQ20WZ11
IC801 410 698 5803 IC S29GL064N90TFI1117--
IC841 310 616 3402 IC PST413A300NR
CAPACITOR
C1041 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C1091 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C1300 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
Key. No. Part No. Description
