Page #106 background imageLoading...
Page #106 background image
Electrical Parts List
KV7-XL51A00
- 106 -
Key. No. Part No. Description
C5214 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5216 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5217 303 367 0410 CERAMIC 0.1U K 50V
C5218 303 391 5115 ELECT 100U M 16V
303 427 8417 ELECT 100U M 16V
303 296 9515 ELECT 100U M 16V
C5219 303 367 0410 CERAMIC 0.1U K 50V
C5221 303 441 9810 CERAMIC 0.01U K 50V
C5222 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5223 303 381 9918 ELECT 470U M 16V
303 407 3517 ELECT 470U M 16V
403 458 5017 ELECT 470U M 16V
C5224 303 441 9810 CERAMIC 0.01U K 50V
C5226 303 381 9918 ELECT 470U M 16V
303 407 3517 ELECT 470U M 16V
403 458 5017 ELECT 470U M 16V
C5227 303 441 9810 CERAMIC 0.01U K 50V
C5229 303 381 9918 ELECT 470U M 16V
303 407 3517 ELECT 470U M 16V
403 458 5017 ELECT 470U M 16V
C5231 303 441 9810 CERAMIC 0.01U K 50V
C5244 303 382 7814 CERAMIC 2.2U K 10V
C531 303 392 1215 ELECT 47U M 6.3V
303 387 5310 ELECT 47U M 6.3V
C532 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C533 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C5332 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C5333 303 376 6311 CERAMIC 0.47U K 10V
C5334 303 320 0419 CERAMIC 68P J 50V
C5336 303 309 2519 CERAMIC 27P J 50V
C5337 303 294 6110 CERAMIC 100P J 50V
C5338 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C534 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C5341 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C535 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C536 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C537 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C538 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C539 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C541 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C542 303 282 5118 CERAMIC 470P K 50V
C543 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C544 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C546 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C547 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C548 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C5601 303 397 5713 ELECT 100U M 10V
303 387 5617 ELECT 100U M 10V
C5602 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5608 303 397 5713 ELECT 100U M 10V
303 387 5617 ELECT 100U M 10V
C561 303 392 1215 ELECT 47U M 6.3V
303 387 5310 ELECT 47U M 6.3V
C5611 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C5612 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C5613 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C5616 303 417 9912 CERAMIC 4.7U K 25V
C5617 303 417 9912 CERAMIC 4.7U K 25V
C5618 303 417 9912 CERAMIC 4.7U K 25V
C5619 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C562 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C5620 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C5621 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C5622 303 358 3215 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C5623 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5624 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C563 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C564 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C5640 303 342 3313 CERAMIC 0.1U K 25V
C5641 303 367 0410 CERAMIC 0.1U K 50V
C5642 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C5643 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5644 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C5646 303 379 7315 CERAMIC 4700P K 50V
C5649 303 391 5115 ELECT 100U M 16V
303 427 8417 ELECT 100U M 16V
303 296 9515 ELECT 100U M 16V
C565 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C5651 303 391 5115 ELECT 100U M 16V
303 427 8417 ELECT 100U M 16V
303 296 9515 ELECT 100U M 16V
C5652 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C566 303 398 5415 ELECT 47U M 25V
303 387 7314 ELECT 47U M 25V
C567 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C568 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C569 303 396 9613 CERAMIC 1U K 25V
303 397 7618 CERAMIC 1U K 25V
C5701 303 367 0410 CERAMIC 0.1U K 50V
C5702 303 398 5415 ELECT 47U M 25V
