Page #110 background image
Electrical Parts List
KV7-XL51A00
- 110 -
Key. No. Part No. Description
R2074 301 224 9910 MT-GLAZE 22K JA 1/16W
R2075 301 225 3818 MT-GLAZE 1.5K JA 1/16W
R2076 301 258 2611 MT-GLAZE 150 FA 1/10W
R2077 301 225 1814 MT-GLAZE 47 JA 1/16W
R2078 301 225 3818 MT-GLAZE 1.5K JA 1/16W
R2079 301 263 7420 MT-GLAZE 75 JA 1/16W
R2081 301 258 2611 MT-GLAZE 150 FA 1/10W
R2082 301 225 1814 MT-GLAZE 47 JA 1/16W
R2083 301 225 3818 MT-GLAZE 1.5K JA 1/16W
R2084 301 263 7420 MT-GLAZE 75 JA 1/16W
R2087 301 258 2611 MT-GLAZE 150 FA 1/10W
R2088 301 258 2611 MT-GLAZE 150 FA 1/10W
R2089 301 258 2611 MT-GLAZE 150 FA 1/10W
R2091 301 258 2611 MT-GLAZE 150 FA 1/10W
R2092 301 225 1814 MT-GLAZE 47 JA 1/16W
R2093 301 225 3818 MT-GLAZE 1.5K JA 1/16W
R2094 301 263 7420 MT-GLAZE 75 JA 1/16W
R2097 301 224 9316 MT-GLAZE 1K JA 1/16W
R2098 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R211 301 225 0619 MT-GLAZE 5.6K JA 1/16W
R2501 301 225 8110 MT-GLAZE 10 JA 1/16W
R2502 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2503 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R2504 301 259 2115 MT-GLAZE 1 JA 1/16W
R2506 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2507 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R2508 301 259 2115 MT-GLAZE 1 JA 1/16W
R2509 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2512 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2513 301 224 8913 MT-GLAZE 100K JA 1/16W
R2514 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2516 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R253 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2531 301 225 8110 MT-GLAZE 10 JA 1/16W
R2532 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2533 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R2534 301 259 2115 MT-GLAZE 1 JA 1/16W
R2536 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2537 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R2538 301 259 2115 MT-GLAZE 1 JA 1/16W
R2539 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R254 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2552 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2553 301 224 8913 MT-GLAZE 100K JA 1/16W
R2554 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2556 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2561 301 225 8110 MT-GLAZE 10 JA 1/16W
R2562 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2563 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R2564 301 259 2115 MT-GLAZE 1 JA 1/16W
R2566 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2567 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R2568 301 259 2115 MT-GLAZE 1 JA 1/16W
R2569 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2572 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2573 301 224 8913 MT-GLAZE 100K JA 1/16W
R2574 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2576 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R262 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R264 301 225 0312 MT-GLAZE 33 JA 1/16W
R266 301 225 0312 MT-GLAZE 33 JA 1/16W
R267 301 225 0312 MT-GLAZE 33 JA 1/16W
R268 301 224 9019 MT-GLAZE 10K JA 1/16W
R269 301 224 8814 MT-GLAZE 100 JA 1/16W
R272 301 225 0312 MT-GLAZE 33 JA 1/16W
R2890 301 224 9712 MT-GLAZE 22 JA 1/16W
R2891 301 224 9712 MT-GLAZE 22 JA 1/16W
R2892 301 224 8814 MT-GLAZE 100 JA 1/16W
R300 301 224 9019 MT-GLAZE 10K JA 1/16W
R302 301 298 5511 MT-GLAZE 8.2K FA 1/16W
R303 301 224 9316 MT-GLAZE 1K JA 1/16W
R304 301 224 9316 MT-GLAZE 1K JA 1/16W
R306 301 339 9614 MT-GLAZE 23.2K FA 1/10W
R307 301 224 9712 MT-GLAZE 22 JA 1/16W
R308 301 224 9712 MT-GLAZE 22 JA 1/16W
R309 301 224 9316 MT-GLAZE 1K JA 1/16W
R311 301 224 9316 MT-GLAZE 1K JA 1/16W
R312 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R313 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R314 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R316 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R318 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R319 301 224 9019 MT-GLAZE 10K JA 1/16W
R321 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R322 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R324 301 225 0817 MT-GLAZE 68K JA 1/16W
R325 301 224 9019 MT-GLAZE 10K JA 1/16W
R327 301 224 9019 MT-GLAZE 10K JA 1/16W
R331 301 224 9712 MT-GLAZE 22 JA 1/16W
R332 301 224 9712 MT-GLAZE 22 JA 1/16W
R334 301 224 9712 MT-GLAZE 22 JA 1/16W
R336 301 224 9712 MT-GLAZE 22 JA 1/16W
R337 301 224 9712 MT-GLAZE 22 JA 1/16W
R338 301 224 9712 MT-GLAZE 22 JA 1/16W
R339 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R340 301 224 8814 MT-GLAZE 100 JA 1/16W
R341 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R342 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R343 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R344 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R347 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R348 301 225 8110 MT-GLAZE 10 JA 1/16W
R349 301 224 9712 MT-GLAZE 22 JA 1/16W
R351 301 225 8110 MT-GLAZE 10 JA 1/16W
R3511 301 224 8814 MT-GLAZE 100 JA 1/16W
R3512 301 224 8814 MT-GLAZE 100 JA 1/16W
R3513 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R3514 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R3515 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R352 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R353 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R355 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R3551 301 224 9019 MT-GLAZE 10K JA 1/16W
R3552 301 224 9910 MT-GLAZE 22K JA 1/16W
R3553 301 224 9910 MT-GLAZE 22K JA 1/16W
R3554 301 224 9019 MT-GLAZE 10K JA 1/16W
R3557 301 225 8110 MT-GLAZE 10 JA 1/16W
R356 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R357 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R3581 301 224 9316 MT-GLAZE 1K JA 1/16W
R3582 301 225 1210 MT-GLAZE 4.7K JA 1/16W
R3583 301 225 1210 MT-GLAZE 4.7K JA 1/16W
R3584 301 225 3818 MT-GLAZE 1.5K JA 1/16W
R359 301 225 8110 MT-GLAZE 10 JA 1/16W
R3601 301 225 3818 MT-GLAZE 1.5K JA 1/16W
R3602 301 225 0619 MT-GLAZE 5.6K JA 1/16W
R3603 301 225 0619 MT-GLAZE 5.6K JA 1/16W
R361 301 302 3410 MT-GLAZE 13K JA 1/16W
R3611 301 224 9019 MT-GLAZE 10K JA 1/16W
R3614 301 224 9019 MT-GLAZE 10K JA 1/16W
