Sanyo PLC-XL51A Service Manual

Electrical Parts List
KV7-XL51A00
- 116 -
Key. No. Part No. Description
L563 945 080 6828 INDUCTOR,3.3U M
L5651 945 062 2855 INDUCTOR,33U M
L5701 945 041 1978 INDUCTOR,330 OHM
L5702 945 038 4579 INDUCTOR,33U M
L5751 945 041 1978 INDUCTOR,330 OHM
L5752 945 041 1978 INDUCTOR,330 OHM
L5753 945 041 1978 INDUCTOR,330 OHM
L6201 945 041 1978 INDUCTOR,330 OHM
L6211 945 041 1978 INDUCTOR,330 OHM
L6801 945 041 1978 INDUCTOR,330 OHM
L6802 645 092 3616 IMPEDANCE,22 OHM P
L6803 645 092 3616 IMPEDANCE,22 OHM P
L6804 645 092 3616 IMPEDANCE,22 OHM P
L8841 945 041 1978 INDUCTOR,330 OHM
L8842 645 092 3616 IMPEDANCE,22 OHM P
L8843 645 092 3616 IMPEDANCE,22 OHM P
DIODE
D1101 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D1102 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D1111 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D1112 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D1371 307 254 2716 DIODE CMS16
D1451 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D1452 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D1801 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D200 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D201 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D2071 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D2091 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D2891 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D2892 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D3551 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3552 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3601 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3611 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3612 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3617 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3621 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3622 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3623 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3624 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3626 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3627 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3628 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3629 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3631 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3632 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D3633 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D4011 307 210 5416 DIODE RB551V-30-TE-17
D4012 307 210 5416 DIODE RB551V-30-TE-17
D4812 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D4813 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D5201 307 210 5416 DIODE RB551V-30-TE-17
D5202 307 210 5416 DIODE RB551V-30-TE-17
D5203 307 210 5416 DIODE RB551V-30-TE-17
D5204 307 210 5416 DIODE RB551V-30-TE-17
D5331 307 210 5416 DIODE RB551V-30-TE-17
D5332 307 210 5416 DIODE RB551V-30-TE-17
D5601 307 201 2724 DIODE RB051L-40-TE25
D5651 307 254 2716 DIODE CMS16
D5704 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D5751 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
307 209 4512 ZD UDZS-TE-176.8B
D6201 307 205 5216 DIODE RB521S-30-TE61
D6202 307 205 5216 DIODE RB521S-30-TE61
D6203 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D6204 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D6211 307 205 5216 DIODE RB521S-30-TE61
D6212 307 205 5216 DIODE RB521S-30-TE61
D6822 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6823 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6824 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6826 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6827 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6828 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6829 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6831 407 264 6312 LED SMLE12Y8W T86
D6832 407 264 6510 LED SMLE12V8W T86
D6833 307 222 4810 LED SML-521MUW T86
D6834 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6836 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D6841 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D6842 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D6843 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D6844 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D6846 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
D8751 407 264 6213 LED SMLE12D8W T86
MISCELLANEOUS
F5751 423 034 3401 FUSE 32V 0.8A
FB602 945 041 1978 INDUCTOR,330 OHM
FB603 945 041 1978 INDUCTOR,330 OHM
Key. No. Part No. Description
