Electrical Parts List
KV7-XL51A00
- 117 -
FB606 945 041 1978 INDUCTOR,330 OHM
FB607 945 041 1978 INDUCTOR,330 OHM
FB609 945 041 1978 INDUCTOR,330 OHM
K20C 645 098 0824 JACK,RCA-3
K30A 645 089 7696 SOCKET,D-SUB 15P
952 001 8601 SOCKET,D-SUB 15P
K30B 645 089 7702 SOCKET,D-SUB 15P
952 001 8571 SOCKET,D-SUB 15P
K40C 945 078 1613 SOCKET,DIN 8P
SC1031 945 076 3503 SURGE-ABSORBER
SC1041 945 076 3503 SURGE-ABSORBER
SC1081 945 076 3503 SURGE-ABSORBER
SC1091 945 076 3503 SURGE-ABSORBER
SC2071 945 076 3503 SURGE-ABSORBER
SC2081 945 076 3503 SURGE-ABSORBER
SC2091 945 076 3503 SURGE-ABSORBER
SC2092 945 076 3503 SURGE-ABSORBER
SC3051 945 076 3503 SURGE-ABSORBER
SC3052 945 076 3503 SURGE-ABSORBER
SW841 945 026 2792 SWITCH,PUSH 1P-1TX1
SWRST 945 026 2792 SWITCH,PUSH 1P-1TX1
X1331 945 088 7179 OSC,CRYSTAL 27.0MHZ
X1801 645 092 8857 OSC,CRYSTAL 48MHZ
X4501 945 060 9900 OSC,CERAMIC 8.00MHZ
X7201 945 079 6372 OSC,CRYSTAL 14.31818MHZ
A2001 610 347 2096 ASSY,PWB,AV.KV7AE
CAPACITOR
C2001 303 358 3215 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C2011 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C2021 303 358 3215 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C2031 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C2051 303 397 8219 CERAMIC 2.2U K 25V
C2052 303 397 8219 CERAMIC 2.2U K 25V
C3001 303 397 8219 CERAMIC 2.2U K 25V
C3011 303 397 8219 CERAMIC 2.2U K 25V
RESISTOR
R2001 301 258 2611 MT-GLAZE 150 FA 1/10W
R2009 301 258 2611 MT-GLAZE 150 FA 1/10W
R2011 301 258 2611 MT-GLAZE 150 FA 1/10W
R2015 301 258 2611 MT-GLAZE 150 FA 1/10W
R2019 301 258 2611 MT-GLAZE 150 FA 1/10W
R2021 301 258 2611 MT-GLAZE 150 FA 1/10W
R2031 301 224 8814 MT-GLAZE 100 JA 1/16W
R2036 301 225 8110 MT-GLAZE 10 JA 1/16W
R2037 301 225 8110 MT-GLAZE 10 JA 1/16W
R2038 301 225 8110 MT-GLAZE 10 JA 1/16W
R2051 301 224 8913 MT-GLAZE 100K JA 1/16W
R2052 301 224 8814 MT-GLAZE 100 JA 1/16W
R2053 301 225 1418 MT-GLAZE 47K JA 1/16W
R2054 301 224 8913 MT-GLAZE 100K JA 1/16W
R2056 301 224 8814 MT-GLAZE 100 JA 1/16W
R2057 301 225 1418 MT-GLAZE 47K JA 1/16W
R3001 301 224 8913 MT-GLAZE 100K JA 1/16W
R3003 301 224 8814 MT-GLAZE 100 JA 1/16W
R3011 301 224 8913 MT-GLAZE 100K JA 1/16W
R3013 301 224 8814 MT-GLAZE 100 JA 1/16W
R3021 301 224 8913 MT-GLAZE 100K JA 1/16W
R3022 301 224 8814 MT-GLAZE 100 JA 1/16W
R3031 301 224 8913 MT-GLAZE 100K JA 1/16W
R3032 301 224 8814 MT-GLAZE 100 JA 1/16W
COIL
L2001 945 068 8318 FILTER,EMI 100MHZ
L2011 945 086 7461 FILTER,EMI 100MHZ
L2021 945 086 7461 FILTER,EMI 100MHZ
L2031 945 086 7461 FILTER,EMI 100MHZ
L2051 945 068 8325 FILTER,EMI 20MHZ
L2052 945 068 8325 FILTER,EMI 20MHZ
L3001 945 068 8325 FILTER,EMI 20MHZ
L3011 945 068 8325 FILTER,EMI 20MHZ
L3021 945 068 8325 FILTER,EMI 20MHZ
L3031 945 068 8325 FILTER,EMI 20MHZ
DIODE
D2031 307 223 0514 ZENER DIODE 02DZ12Y(TPH3)
MISCELLANEOUS
K20A 645 089 9041 SOCKET,DIN 4P
K20B 645 098 0831 JACK,RCA-3
K40A 945 006 4792 JACK,PHONE D3.6
K40B 945 006 4792 JACK,PHONE D3.6
SC2001 945 076 3503 SURGE-ABSORBER
SC2011 945 076 3503 SURGE-ABSORBER
SC2021 945 076 3503 SURGE-ABSORBER
SC2031 945 076 3503 SURGE-ABSORBER
SC2051 945 076 3503 SURGE-ABSORBER
SC2052 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3011 945 076 3503 SURGE-ABSORBER
SC3021 945 076 3503 SURGE-ABSORBER
SC3031 945 076 3503 SURGE-ABSORBER
A2901 610 347 2126 ASSY,PWB,R/C.KV7AE
CAPACITOR
C2901 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C2902 303 282 5118 CERAMIC 470P K 50V
C2903 303 380 0114 CERAMIC 47U M 6.3V
RESISTOR
R2901 301 225 1814 MT-GLAZE 47 JA 1/16W
R2902 301 224 8814 MT-GLAZE 100 JA 1/16W
MISCELLANEOUS
A2901 945 084 1997 UNIT,REMOCON RECEIVER
A690 610 347 2119 ASSY,PWB,LAMP COVER SW.KV7AE
SW901 945 063 5176 SWITCH,PUSH 2P-2TX3
A4831 610 347 2133 ASSY,PWB,TEMP.KV7AE
CAPACITOR
C4831 303 276 3113 CERAMIC 33P J 50V
C4832 303 276 3113 CERAMIC 33P J 50V
C4833 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C4834 303 379 6714 CERAMIC 10U K 16V
Key. No. Part No. Description Key. No. Part No. Description
