Sanyo PLC-XL51A Service Manual

Electrical Parts List
KV7-XL51A00
- 118 -
Key. No. Part No. Description
RESISTOR
R4831 301 225 8110 MT-GLAZE 10 JA 1/16W
R4832 301 225 8110 MT-GLAZE 10 JA 1/16W
R4833 301 224 9019 MT-GLAZE 10K JA 1/16W
A6801 610 347 2157 ASSY,PWB,KEY SW.KV7AE
CAPACITOR
C6801 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C6802 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C6803 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C6804 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C6806 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
C6807 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R6800 301 225 1517 MT-GLAZE 3.9K JA 1/16W
R6801 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R6802 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6804 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R6806 301 224 9217 MT-GLAZE 15K JA 1/16W
R6807 301 234 9917 MT-GLAZE 6.8K JA 1/16W
R6808 301 225 1517 MT-GLAZE 3.9K JA 1/16W
R6809 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R6811 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6812 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R6821 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R6822 301 224 8814 MT-GLAZE 100 JA 1/16W
DIODE
D6801 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D6802 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
D6803 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
MISCELLANEOUS
SW6800 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6801 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6802 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6803 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6804 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6806 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6807 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6808 945 026 2792 SWITCH,PUSH 1P-1TX1
SW6811 945 026 2792 SWITCH,PUSH 1P-1TX1
A200 610 347 2140 ASSY,LED.KV7AE
CAPACITOR
C251 303 438 0219 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
DIODE
D251 407 264 6411 LED SMLE12M8W T86
D252 407 264 6411 LED SMLE12M8W T86
D253 307 223 1115 ZENER DIODE 02DZ6.2Y(TPH3
307 209 1214 ZD UDZS-TE-176.2B
Key. No. Part No. Description
