Sanyo PLC-XL51A Service Manual

- 54 -
Group/ Item
Item Name Function Initial Range Note
162 PreCoast YCbCr 1080i 60Hz 7 0 - 63
163 PostCoast YCbCr 1080i 60Hz 13 0 - 63
164 PreCoast YCbCr 1080i 50Hz 7 0 - 63
165 PostCoast YCbCr 1080i 50Hz 13 0 - 63
166 PreCoast YCbCr 1035i 7 0 - 63
167 PostCoast YCbCr 1035i 13 0 - 63
180 PreCoast SCART 480i 7 0 - 63
181 PostCoast SCART 480i 13 0 - 63
182 PreCoast SCART 575i 7 0 - 63
183 PostCoast SCART 575i 13 0 - 63
Group 10 Sync Processor
0 SYNCAMPHLCKTOLOW
Minimum sync amplitude threshold
for HLCK 1 to 0 tansition
0x700 0 - 9999
1 SYNCAMPHLCKTOHI
Minimum sync amplitude threshold
for HLCK 0 to 1 tansition
0x1000 0 - 9999
Group 20 Video Decoder *R : Read Only Value
0 Y Level
Composite / S-Video - Y Level (ADC
RGB Gain)
10/10 0 - 255
Composite / S-Video
1 C Level
Composite / S-Video - C Level (ADC
Saturation)
115/115 0 - 255 Composite / S-Video
2
3 XCXL Level Cross-Chroma, Cross-Luma Level 3 0 - 5
4 C2DNBANDWIDTH Comb 2D Narrow Bandwidth 3 / 3 0 - 3 NTSC/PAL
5 C2DWBANDWIDTH Comb 2D Wide Bandwidth 4 / 4 0 - 7 NTSC/PAL
6 C2DCNMINLEAK
Comb 2D Chroma Narrow Band
Minimum Leakage
0 / 3 0 - 3
Left Values are adjustable if CXCL
Level = 5.
7 C2DCNSLOPELEAK
Comb 2D Narrow Band Slope
Leakage
7 / 7 0 - 7 NTSC/PAL
8 C2DCWMINLEAK
Comb 2D Wide Band Minimum
Leakage
1 / 3 0 - 3 NTSC/PAL
9 C2DCWSLOPELEAK Comb 2D CW Slope Leakage 6 / 6 0 - 7 NTSC/PAL
10 COMBLEAK2BPGAIN Comb Leak To Ban Pass Gain 1 / 0 0 - 3 NTSC/PAL
11 C2DBDIAGONALGAIN Comb 2D Band Pass Diagonal Gain 1 / 3 0 - 3 NTSC/PAL
12 C2DNBCWBCLGAIN
Comb 2D Narrow Band Comb Wide
Band Comb
1 / 1 0 - 3 NTSC/PAL
13 RLUMASETUP-Enable 7.5IRE Setup Enable 0 0 - 1 Eective only NTSC Signal
Group 40 General
0 IP Mode Sets for IP O 1 0 - 1
0: IP Block not used
1: IP OFF used with IP Block
1 3:2 PullDown Mode 1 1 - 3
bit0 : Global Motion
bit1 : Video Motion
2 Detect Film Mode Enable 0 0 - 2
0 : 2:3pull down & 2:2pull down
1 : 2:3pull down
2 : 2:2pull down
3 Force IP Mode 2 0 - 2
0 : IP Process Disable
1 : Force Normal IP Mode
2 : Force Film Mode
Eective only for PSF Signal.
Group 41 Deinterlacer setting Eective only for Progressive ON-L1 mode.
0 Motion Adaptive Weight Value <KDEINT> 30 0 - 255
1 Angle Interpolation Level
0 : Conservative <====> 4 :
Aggressive
4 0 - 4
2 CUE Low Pass Filter Enable <CUELPFEN> 0 0 - 1
Group 42 Deinterlacer setting Eective only for Progressive ON-L2 mode.
0 Motion Adaptive Weight Value <KDEINT> 0 0 - 255
1 Angle Interpolation Level
0 : Conservative <====> 4 :
Aggressive
2 0 - 4
2 CUE Low Pass Filter Enable <CUELPFEN> 0 0 - 1
Group 43 Deinterlacer setting Eective only for Progressive ON/Film mode.
0 Motion Adaptive Weight Value <KDEINT> 30 0 - 255
1 Angle Interpolation Level
0 : Conservative <====> 4 :
Aggressive
4 0 - 4
2 CUE Low Pass Filter Enable <CUELPFEN> 0 0 - 1
Group 45 Noise Reduction (Time) ective only for N.R - O
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
Service Adjustment
