Sanyo PLC-XL51A Service Manual

- 55 -
Service Adjustment
Group/ Item
Item Name Function Initial Range Note
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 0 0 - 255
Group 47 Noise Reduction (Time) Eective only for N.R L1
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 50 0 - 255
Group 49 Noise Reduction (Time) Eective only for N.R L2
0 Noise Pixel Range <NSRANGEY> / <NSRANGEUV> 1 0 - 2
1 Noise Region 0 <NSREGIONY0> / <NSREGIONUV0> 12 0 - 1023
2 Noise Region 1 <NSREGIONY1> / <NSREGIONUV1> 24 0 - 1023
3 Noise Region 2 <NSREGIONY2> / <NSREGIONUV2> 40 0 - 1023
4 Noise Gain Level <NSFILTERY**> / <NSFILTERUV**> 100 0 - 255
Group 50 2:2pull down setting
0 22Film Mode Sensitivity
Film Detection Sensitivity
<FILMSTVT22>
4 1 - 5
1 22Film Mode Threshold Low <FILMTHRD22A> 80 0 - 32767
2 22Film Mode Threshold High <FILMTHRD22B> 120 0 - 32767
3 VOFTHR13 <VOFTHR13> 124 0 - 1023 Read only
4 VOFTHR12 <VOFTHR12> 124 0 - 1023 Read only
5 VOFTHR23 <VOFTHR23> 124 0 - 1023 Read only
6 Video Motion Window Start X <VOFSTARX> 10 0 - 2047 Range of detective for Film mode
7 Video Motion Window Stop X <VOFSTOPX> 10 0 - 2047 Range of detective for Film mode
8 Video Motion Window Start Y <VOFSTARY> 10 0 - 1023 Range of detective for Film mode
9 Video Motion Window Stop Y <VOFSTOPY> 10 0 - 1023 Range of detective for Film mode
Group 51 2:3pull down setting
0 Global Motion Sensitivity
Film Detection Sensitivity
<FILMSTVT23>
4 1 - 5
1 Video Motion Sensitivity
Film Detection Sensitivity
<VOFSTVT>
4 1 - 5
2 Video Motion Threshold Low <VOFTHRDA> 120 0 - 32767
3 Video Motion Threshold High <VOFTHRDB> 180 0 - 32767
4 Global Motion Threshold <GMDTHRD> 124 0 - 1023 Read only
5 23Film Mode Threshold <FILMTHRD23> 100 0 - 32767
6 Global Motion Window Start X <GMDSTARX> 10 0 - 2047 Range of detective for Film mode
7 Global Motion Window Stop X <GMDSTOPX> 10 0 - 2047 Range of detective for Film mode
8 Global Motion Window Start Y <GMDSTARY> 10 0 - 1023 Range of detective for Film mode
9 Global Motion Window Stop Y <GMDSTOPY> 10 0 - 1023 Range of detective for Film mode
Group 55 LTI / CTI
0 DC TIEN 0 0 - 1
1 DC TILBB 0 0 - 1
2 DC TISELBAND 0 0 - 1
3 DC TILBGAIN 3 0 - 63
4 DC TIBGAIN 63 0 - 63
5 DC TICOR 8 0 - 31
6 PEAKOVER1 255 0 - 255
7 PEAKOVER2 255 0 - 255
8 PEAKEN 0 0 - 1
9 PEAKBKGAIN 0 0 - 1
10 PEAKREFSEL 0 0 - 1
11 PEAKB 0 0 - 3
12 PEAKH 3 0 - 3
13 PEAKLPGAIN 2 0 - 63
14 PEAKLHGAIN 1 0 - 63
15 PEAKCOR 0 0 - 31
16 PEAKREFGAIN 16 0 - 63
