Sanyo PLC-XL51A Service Manual

- 58 -
Service Adjustment
Group/ Item
Item Name Function Initial Range Note
121 CSC_G_GP3 241 0-511
122 CSC_G_GP4 196 0-511
123 CSC_G_GP5 0 0-511
124 CSC_G_GP6 0 0-511
125 CSC_G_GP7 0 0-511
126 CSC_G_GP8 0 0-511
127 CSC_B_GP1 319 0-511
128 CSC_B_GP2 285 0-511
129 CSC_B_GP3 235 0-511
130 CSC_B_GP4 179 0-511
131 CSC_B_GP5 0 0-511
132 CSC_B_GP6 0 0-511
133 CSC_B_GP7 0 0-511
134 CSC_B_GP8 0 0-511
135 SHAD_GSEL 1 0-3
136 SHAD_R_CALC 1 0-1
137 SHAD_G_CALC 1 0-1
138 SHAD_B_CALC 1 0-1
139 SHAD_ON 1 0-1
140 SHAD_R_DAT1 37 0-255
141 SHAD_R_DAT2 18 0-255
142 SHAD_R_DAT3 12 0-255
143 SHAD_G_DAT1 37 0-255
144 SHAD_G_DAT2 18 0-255
145 SHAD_G_DAT3 12 0-255
146 SHAD_B_DAT1 37 0-255
147 SHAD_B_DAT2 18 0-255
148 SHAD_B_DAT3 12 0-255
149 SHAD_COEF 1351 0-4095
150 VS_GSEL 0 0-3
151 VS_R_RGT 0 0-1
152 VS_G_RGT 0 0-1
153 VS_B_RGT 0 0-1
154 VS_CYCLE 0 0-1
155 VS_ON 0 0-1
156 VS_GDAT1 0 0-255
157 VS_DAT 0 0-255
158 VS_GDAT3 0 0-255
159 VS_GDAT2 0 0-255
160 HXT_TH4_ON 0 0-1
161 HXT_TH3_ON 0 0-1
162 HXT_TH2_ON 0 0-1
163 HXT_TH1_ON 0 0-1
164 HXT_ON 0 0-1
165 HXT_R_CALC 0 0-1
166 HXT_G_CALC 0 0-1
167 HXT_B_CALC 0 0-1
168 HXT_GSEL 0 0-3
169 HXT_RDAT1 0 0-255
170 HXT_RDAT2 0 0-255
171 HXT_RDAT3 0 0-255
172 HXT_GDAT1 0 0-255
173 HXT_GDAT2 0 0-255
174 HXT_GDAT3 0 0-255
175 HXT_BDAT1 0 0-255
176 HXT_BDAT2 0 0-255
177 HXT_BDAT3 0 0-255
178 HXT_TH1 0 0-255
179 HXT_TH2 0 0-255
180 HXT_TH3 0 0-255
181 HXT_TH4
0
0-255
182 SEL_MODE2
0
0-7
200 IRE_L1
12
0-100
201 IRE_L2
25
0-100
202 IRE_L3
50
0-100
203 IRE_L4
75
0-100
204 C0lshd Level R min
199
0-511
205 C0lshd Level R
232
0-511
206 C0lshd Level R
281
0-511
