Sanyo PLC-XL51A Service Manual

Electrical Parts List
KV7-XL51A00
- 96 -
Key. No. Part No. Description
C673 303 410 7113 ELECT 100U M 25V
C674 403 478 9019 MT-POLYEST 0.01U J 630V
RESISTOR
R611 401 353 0311 MT-GLAZE 430K JA 1/3W
R612 401 353 0212 MT-GLAZE 360K JA 1/3W
R613 301 256 6314 MT-GLAZE 47K JA 1/10W
R614 402 109 8206 RESISTER 0.15 JB 5W
R615 401 361 2611 MT-GLAZE 680K DA 1/4W
R616 401 361 2611 MT-GLAZE 680K DA 1/4W
R617 301 256 6314 MT-GLAZE 47K JA 1/10W
R618 401 361 7111 MT-GLAZE 680K JA 1/3W
R619 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R620 301 256 5614 MT-GLAZE 47 JA 1/10W
R621 301 326 1812 MT-GLAZE 8.2K DA 1/10W
R622 301 309 8517 MT-GLAZE 330 DA 1/10W
R623 401 360 8010 MT-GLAZE 470 DA 1/10W
R624 301 162 2912 MT-GLAZE 220 JA 1/10W
R625 301 256 5614 MT-GLAZE 47 JA 1/10W
R626 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R627 301 150 5918 MT-GLAZE 10K JA 1/10W
R628 301 150 5918 MT-GLAZE 10K JA 1/10W
R629 301 255 7312 MT-GLAZE 510K JA 1/10W
R631 301 255 7718 MT-GLAZE 11K JA 1/10W
R632 401 361 7111 MT-GLAZE 680K JA 1/3W
R633 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R634 301 256 1715 MT-GLAZE 33K JA 1/10W
R635 401 361 2710 MT-FILM 0.39 JA 1W
R636 301 162 3018 MT-GLAZE 22K JA 1/10W
R637 301 256 7212 MT-GLAZE 18K JA 1/10W
R638 301 256 6314 MT-GLAZE 47K JA 1/10W
R641 301 150 5918 MT-GLAZE 10K JA 1/10W
R642 301 256 6611 MT-GLAZE 68K JA 1/10W
R643 301 150 5918 MT-GLAZE 10K JA 1/10W
R644 301 150 5918 MT-GLAZE 10K JA 1/10W
R646 301 256 7212 MT-GLAZE 18K JA 1/10W
R648 301 256 7212 MT-GLAZE 18K JA 1/10W
R651 301 150 5918 MT-GLAZE 10K JA 1/10W
R652 301 292 1915 MT-GLAZE 22 FA 1/2W
R662 301 152 3219 MT-GLAZE 330 JA 1/10W
R665 301 242 2313 MT-GLAZE 82K JA 1/2W
R671 301 256 7618 MT-GLAZE 3.9K JA 1/10W
R672 301 150 6212 MT-GLAZE 1K JA 1/10W
R673 301 264 2919 MT-GLAZE 12K FA 1/10W
R674 301 264 7518 MT-GLAZE 2.7K FA 1/10W
R675 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R676 301 264 2810 MT-GLAZE 1.2K FA 1/10W
R683 301 265 0211 MT-GLAZE 390 FA 1/10W
R684 301 264 9314 MT-GLAZE 3.3K FA 1/10W
R685 402 109 8206 RESISTER 0.15 JB 5W
R686 301 258 8217 MT-GLAZE 680 JA 1/3W
R687 302 080 8809 MT-GLAZE 680 KA 1W
R689 301 242 2313 MT-GLAZE 82K JA 1/2W
R690 301 242 2313 MT-GLAZE 82K JA 1/2W
R691 301 242 2313 MT-GLAZE 82K JA 1/2W
R692 301 150 6212 MT-GLAZE 1K JA 1/10W
R693 301 162 2417 MT-GLAZE 1.2K JA 1/10W
TRANSFORMER
! T651 645 097 6483 TRANS,POWER,PULSE
COIL
! L611 945 081 4878 LINE FILTER
L612 645 089 2561 INDUCTOR,700U
L613 910 244 3975 CORE
L614 910 244 3975 CORE
L631 910 078 5954 PIPE CORE
L661 910 244 3975 CORE
L662 910 244 3975 CORE
L663 945 041 1978 INDUCTOR,330 OHM
DIODE
D611 307 225 4401 DIODE FMX-G26S
D612 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D613 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D631 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D632 307 247 8827 DIODE RF101L2S
D633 307 146 8116 DIODE EG01C
D651 307 247 8827 DIODE RF101L2S
D661 407 261 9504 DIODE YG862C10R
D662 307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
D663 307 247 8827 DIODE RF101L2S
D664 307 210 5416 DIODE RB551V-30-TE-17
D665 307 219 0808 THYRISTOR TF861S
D666 307 146 8116 DIODE EG01C
DB611 307 143 6006 DIODE RBV-1506
308 045 4909 DIODE RBV-1506 LF-B
408 069 8904 DIODE RBV-1506 LF035-40
MISCELLANEOUS
! F631 324 006 1305 FUSE 250V 2.5A
! PC661 407 265 7813 PC TLP781F(D4-GB-TP7)
! PC663 407 265 7813 PC TLP781F(D4-GB-TP7)
! PC671 407 265 7813 PC TLP781F(D4-GB-TP7)
PTH611 308 037 5600 THERMISTOR NTPDB8R0LDHB0
PTH641 408 068 9803 TH PRF18BD471QB5RB
ZD631 307 206 5413 ZD UDZS-TE-178.2B
A602 610 347 8586 ASSY,PWB,LINE FILTER LM3WB
CAPACITOR
! C601 404 113 2904 MT-POLYEST 0.33U K 275V
! C602 404 113 2904 MT-POLYEST 0.33U K 275V
! C603 304 104 9502 CERAMIC 1500P K 250V
! C604 304 104 9502 CERAMIC 1500P K 250V
RESISTOR
! R600 301 242 5314 MT-GLAZE 470K JA 1/2W
! R601 301 242 5314 MT-GLAZE 470K JA 1/2W
VARIABLE RESISTOR
! VA601 408 066 1700 VD TND14SE471KB0SLAA0
COIL
! L601 945 050 2232 LINE FILTER
MISCELLANEOUS
! F601 323 025 1204 FUSE 250V 8A
! K601 645 097 0863 UNIT,NOISE FILTER
A1001 610 347 2072 ASSY,PWB,MAIN.KV7AE
TRANSISTOR
Q1051 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
Key. No. Part No. Description
