Sanyo PLC-XM100L Service Manual

Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
-146-
KA8-XM15000 / KA8-XM150L00
KZ5-XM10000 / KZ5-XM100L00
R5002 301 225 8110 MT-GLAZE 10 JA 1/16W
R5003 301 225 8110 MT-GLAZE 10 JA 1/16W
R5031 301 224 8814 MT-GLAZE 100 JA 1/16W
R5032 301 224 8814 MT-GLAZE 100 JA 1/16W
R5033 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R5034 301 224 9316 MT-GLAZE 1K JA 1/16W
R5036 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R5037 301 224 9316 MT-GLAZE 1K JA 1/16W
R5061 301 224 9316 MT-GLAZE 1K JA 1/16W
R5062 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R5063 301 224 9316 MT-GLAZE 1K JA 1/16W
R5064 301 224 9316 MT-GLAZE 1K JA 1/16W
R5066 301 225 0213 MT-GLAZE 3.3K JA 1/16W
R5067 301 224 9316 MT-GLAZE 1K JA 1/16W
R5069 301 225 8011 MT-GLAZE 330 JA 1/16W
COIL
L2001 945 086 7577 FILTER,EMI 400MHZ
L2002 945 086 7577 FILTER,EMI 400MHZ
L2003 945 086 7577 FILTER,EMI 400MHZ
L2004 945 086 7560 FILTER,EMI 200MHZ
L2006 945 086 7560 FILTER,EMI 200MHZ
L2007 301 035 4111 MT-GLAZE 0.000 ZA 1/8W
L2821 945 086 7454 FILTER,EMI 50MHZ
L2822 945 086 7454 FILTER,EMI 50MHZ
L3001 945 086 7577 FILTER,EMI 400MHZ
L3002 945 086 7577 FILTER,EMI 400MHZ
L3003 945 086 7577 FILTER,EMI 400MHZ
L3004 945 086 7461 FILTER,EMI 100MHZ
L3006 945 086 7461 FILTER,EMI 100MHZ
L3803 945 070 3660 INDUCTOR,90 OHM
L3804 945 059 2240 INDUCTOR,2.2U M
L3811 945 086 7454 FILTER,EMI 50MHZ
L3812 945 086 7454 FILTER,EMI 50MHZ
L3813 945 086 7454 FILTER,EMI 50MHZ
L3814 945 086 7454 FILTER,EMI 50MHZ
L3815 945 086 7454 FILTER,EMI 50MHZ
L3816 945 086 7454 FILTER,EMI 50MHZ
L3817 945 086 7454 FILTER,EMI 50MHZ
L3818 945 086 7454 FILTER,EMI 50MHZ
L8166 945 086 5368 IMPEDANCE,220 OHM P
DIODE
D2821 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D2822 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D2823 307 254 2914 ZENER DIODE 02DZ6.8Y(TPH3
D5061 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
D5062 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
MISCELLANEOUS
IC2821 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
K20C 945 086 7676 SOCKET,BNC 1P
645 099 2209 SOCKET,BNC 1P
K20D 645 067 7267 SOCKET,BNC 4P
645 099 2216 SOCKET,BNC 4P
K30A 652 003 0480 JACK,RCA-2
K30B 945 067 6124 TERMINAL,BOARD
952 001 7932 TERMINAL, BOARD
K30C 652 003 0473 JACK,RCA-2
K30D 945 076 2742 JACK,PHON D3.6
652 002 1808 JACK,PHONE D3.6
652 002 4847 JACK,PHONE D3.6
K30E 945 076 2742 JACK,PHON D3.6
652 002 1808 JACK,PHONE D3.6
652 002 4847 JACK,PHONE D3.6
K38B 645 095 2647 SOCKET,USB 4P
SC1007 945 076 3503 SURGE-ABSORBER
SC1008 945 076 3503 SURGE-ABSORBER
SC2001 945 076 3503 SURGE-ABSORBER
SC2002 945 076 3503 SURGE-ABSORBER
SC2003 945 076 3503 SURGE-ABSORBER
SC2004 945 076 3503 SURGE-ABSORBER
SC2006 945 076 3503 SURGE-ABSORBER
SC3001 945 076 3503 SURGE-ABSORBER
SC3002 945 076 3503 SURGE-ABSORBER
SC3003 945 076 3503 SURGE-ABSORBER
SC3004 945 076 3503 SURGE-ABSORBER
SC3006 945 076 3503 SURGE-ABSORBER
SC3813 945 076 3503 SURGE-ABSORBER
SC3814 945 076 3503 SURGE-ABSORBER
SC3815 945 076 3503 SURGE-ABSORBER
SC3816 945 076 3503 SURGE-ABSORBER
SC3817 945 076 3503 SURGE-ABSORBER
SC3818 945 076 3503 SURGE-ABSORBER
SC3819 945 076 3503 SURGE-ABSORBER
SC3821 945 076 3503 SURGE-ABSORBER
A3600 655 003 0962 ASSY,PWB,NET JOINT KA8AL
TRANSISTOR
Q3601 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3602 305 047 9010 TR 2SB1204-S-TL-E
Q3603 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC1883 309 246 9710 IC LA6358NM-TE-L-E
IC9887 309 673 9819 IC PQ070XNA1ZPH
CAPACITOR
C1886 303 409 3426 CERAMIC 0.1U K 16V
C1890 303 358 3215 CERAMIC 10U K 6.3V
303 370 0018 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C1891 303 409 3426 CERAMIC 0.1U K 16V
C1892 303 409 3426 CERAMIC 0.1U K 16V
C1893 303 409 3426 CERAMIC 0.1U K 16V
C3610 303 409 3426 CERAMIC 0.1U K 16V
C3611 303 381 5316 ELECT 100U M 16V
C3612 303 409 3426 CERAMIC 0.1U K 16V
C3613 303 358 8319 CERAMIC 1U K 10V
C3614 303 358 8319 CERAMIC 1U K 10V
C3615 303 358 3215 CERAMIC 10U K 6.3V
303 370 0018 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C3616 303 367 0410 CERAMIC 0.1U K 50V
303 370 1510 CERAMIC 0.1U K 50V
C3617 303 409 3426 CERAMIC 0.1U K 16V
C3619 303 381 5316 ELECT 100U M 16V

Sanyo PLC-XM100L Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Lamp type	NSH
Lamp power	330 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Analog signal format system	NTSC, PAL, SECAM
S-Video inputs quantity	1
Dimensions (WxDxH)	489.5 x 371.1 x 164 mm
Noise level	38 dB
Power consumption (standby)	0.6 W
Power consumption (typical)	400 W
Power consumption (economy mode)	338 W

Weight and Dimensions

Weight	8900 g
